Infiniti G35 III (2002-2007) passenger side tweeter Wiring diagrams
This page contains all the electrical diagrams for the component. passenger side tweeter, in which he is found in the car Infiniti G35 III (2002-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passenger side tweeter (1 of 2)
11 12 13 14 15 16 GND
41 42 43 44 RX TX
A/T W/O NAVIGATION SYSTEM, SUNROOF
ANT MAIN
ANT SIG
AUDIO UNIT
BLK WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE)
DOWN
DRIVER DOOR SPEAKER
DRIVER SIDE TWEETER
FEEDER CABLE ANTENNA (SUB)
FUSE 37
FUSE 6
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BOX
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
ILLUM
LEFT REAR SPEAKER
LIGHTING SWITCH GND
LT GRN WIRE
M/T W/ NAVIGATION SYSTEM, SUNROOF
MODE
NAVI INPUT (-) NAVI GND NAVI INPUT (+)
NAVIGATION SYSTEM
NCA WIRE
OFF
OFF ON
OPTION CONNECTOR (FOR SATELLITE RADIO RECEIVER)
ORG/ WIRE
ORG/BLU WIRE
PASSENGER DOOR SPEAKER
PASSENGER SIDE TWEETER
PNK WIRE
POWER
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
REM CONTROL A REM CONTROL B NAVI ON REM CONTROL GND
REQ+
RIGHT REAR SPEAKER
RR SP LH (-) RR SP LH (+) RR SP RH (-) RR SP RH (+)
SEEK
SPEED SIGNAL
STEERING WHEEL/ AUDIO CONTROL SWITCH
SWITCH
UNIFIED METER CONTROL UNIT
VOLUME-
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WINDOW ANTENNA (MAIN)
WINDOW ANTENNA (SUB)
YEL WIRE
Go to component -> Radio circuit, coupe with base system -> PASSENGER SIDE TWEETER
Wiring diagram passenger side tweeter (2 of 2)
1 2 3 4 BACK UP WOOFER OUT (-) WOOFER OUT (-)
11 12 GND AMP ON SIGNAL
13 14 RR SP LH (-) AMP RR SP LH (+) AMP
15 16 PNK RR SP RH (-) AMP RR SP RH (+) AMP WIRE
17 18 19 20 GROUND WOOFER OUT (+) WOOFER OUT (+)
3 4 FR SP RH (-) AMP FR SP RH (+) AMP
5 6 7 8 9 10 ANT SIGNAL BACK-UP
ANT MAIN
ANT SIG
ANT SIGNAL FR SP LH (-) AMP FR SP LH (+) AMP 1 2
AUDIO UNIT
BLK WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BOSE SPEAKER AMPLIFIER (AT LEFT REAR OF TRUNK)
BRN WIRE
COMBINATION METER
COMBINATION SWITCH
DATA GND RX TX
DOWN
DRIVER DOOR SPEAKER
DRIVER SIDE TWEETER
FEEDER CABLE ANT SIGNAL
FUSE 37
FUSE 6
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BOX
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
ILLUM
LEFT REAR SPEAKER
LEFT WOOFER
LIGHTING SWITCH EARTH
LT BLU WIRE
LT GRN WIRE
MODE
NAVI IN (-) NAVI GND NAVI IN (+)
NAVIGATION SYSTEM
NCA WIRE
OFF
OFF ON
OPTION CONNECTOR (FOR SATELLITE RADIO RECEIVER)
ORG/ WIRE
ORG/BLU WIRE
PASSENGER DOOR SPEAKER
PASSENGER SIDE TWEETER
POWER
PPL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
REM CONTROL A REM CONTROL B NAVI ON REM CONTROL GND
RIGHT REAR SPEAKER
RIGHT WOOFER
SEEK
SPEED SIGNAL
STEERING WHEEL/ AUDIO CONTROL SWITCH
SWITCH
UNIFIED METER CONTROL UNIT
VOLUME-
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WINDOW ANTENNA (MAIN)
WINDOW WINDOW ANTENNA ANTENNA (SUB)
YEL WIRE
YEL/RED WIRE
Go to component -> Radio circuit, coupe with bose system -> PASSENGER SIDE TWEETER
