Infiniti G35 III (2002-2007) high mounted stoplamp lamp Wiring diagram
This page shows the only wiring diagram for the component.high mounted stoplamp lamp, which is found in the car Infiniti G35 III (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high mounted stoplamp lamp (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CAN-L CAN-H
CPU TAIL/LAMP RLY
FUSE 71
FUSE 78
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE 20
GND (SIGNAL)
GND POWER
GRN WIRE
GRN/WHT WIRE
HIGH MOUNTED STOPLAMP
HIGH MOUNTED STOPLAMP LAMP
HOT AT ALL TIMES
LEFT FRONT COMBINATION LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT LICENSE PLATE
LEFT REAR COMBINATION LAMP
PARKING
PNK 3 4 WIRE
PNK WIRE
PNK/BLU WIRE
PPL
PPL/WHT WIRE
RED WIRE
RED/BLU WIRE
RIGHT FRONT COMBINATION LAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT LICENSE PLATE LAMP
RIGHT REAR COMBINATION LAMP
SIDE MARKER
SIDE MARKER TURN
STOP LAMP IN THE REAR AIR SPOILER
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
TAIL STOP
TAILLAMP RELAY
TURN
W/ HIGH MOUNTED
W/ HIGH MOUNTED STOP LAMP IN THE REAR PARCEL SHELF
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, sedan (2 of 2) -> HIGH MOUNTED STOPLAMP LAMP
