Infiniti G35 III (2002-2007) hazard switch illumination Wiring diagram
This page shows the only wiring diagram for the component.hazard switch illumination, which is found in the car Infiniti G35 III (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hazard switch illumination (1 of 1)
+IG
8 8 7 LIGHTING SW ILLUM CTRL
ASCD STEERING SWITCH
ASHTRAY ILLUMINATION
AUDIO UNIT
B+ B-
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CAN L
CIGARETTE LIGHTER SOCKET ILLUMINATION
COMBINATION SWITCH (SPIRAL CABLE)
COMPUTER DATA LINES SYSTEM
COUPE
CPU TAIL/L RLY
FUSE 71
FUSE 78
GLOVE BOX LAMP)
GND (POWER) GND (SIGNAL) CAN-H
HAZARD SWITCH ILLUMINATION
HEATED SEAT SWITCH (DRIVER SIDE) (ILLUMINATION)
HEATED SEAT SWITCH (PASSENGER SIDE) (ILLUMINATION)
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION RELAY
ILLUMINATION CONTROL SWITCH
LIGHTING SW
NCA WIRE
PNK WIRE
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RESISTOR (BEHIND LEFT SIDE OF DASH)
SEDAN
SEDAN, COUPE
SNOW MODE SWITCH (ILLUMINATION) (SEDAN: AWD MODEL)
STEERING WHEEL AUDIO CONTROL SWITCH (IF EQUIPPED)
TAILLAMP RELAY
UPPER GLOVE BOX LAMP (W/O NAVIGATION)
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> HAZARD SWITCH ILLUMINATION
