Infiniti G35 III (2002-2007) fuse 74 fuse 72 fuse 86 fuse 76 wiring diagram
This page shows the only wiring diagram for the component.fuse 74 fuse 72 fuse 86 fuse 76, which is found in the car Infiniti G35 III (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
fuse 74 fuse 72 fuse 86 fuse 76 wiring diagram (1 of 1)
1 2 3 PNK POWER OUTPUT GROUND WIRE
BLK WIRE
BLU WIRE
BRN WIRE
CAN-L CAN-H
COMPUTER DATA LINES SYSTEM
CPU FR FOG
FRONT FOG LAMP RELAY
FUSE 74 FUSE 72 FUSE 86 FUSE 76
FUSE 78
FUSE 88
GND (SIGNAL)
GND POWER
GRN WIRE
H/LP LO H/LP HI
HEAD LAMP (LOW)
HEAD- LAMP HIGH FOG LAMP
HEADLAMP HIGH RELAY
HEADLAMP LOW RELAY
HID CONT
HOT AT ALL TIMES
LEFT FRONT COMBINATION LAMP
LT BLU WIRE
OPTICAL SENSOR (W/ AUTOLIGHT OPTION) (AT TOP RIGHT OF DASH)
PNK 1 2 3 WIRE
PNK WIRE
RED WIRE
RIGHT FRONT COMBINATION LAMP
WHT WIRE
YEL WIRE
YEL/PPL WIRE
Go to component -> Headlights circuit, without drl (2 of 2) -> FUSE 74 FUSE 72 FUSE 86 FUSE 76
