Infiniti G35 III (2002-2007) driver side door switch (on left front side of Wiring diagram
This page shows the only wiring diagram for the component.driver side door switch (on left front side of, which is found in the car Infiniti G35 III (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver side door switch (on left front side of (1 of 1)
A/T DEVICE (PARKING POSITION SWITCH) (UNDER CENTER CONSOLE)
A/T M/T
BACKWARD FORWARD
BATT (PTC)
BATT FUSE
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
CIRCUIT BREAKER (BEHIND LEFT SIDE OF DASH)
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DIODE
DN UP FRONT
DOOR SW (DR)
DRIVER SEAT CONTROL UNIT
DRIVER SIDE DOOR SWITCH (ON LEFT FRONT SIDE OF
DRIVER SIDE SEAT BELT BUCKLE SWITCH (IN DRIVER SEAT BELT BUCKLE)
FOR- WARD BACK- WARD
FUSE 18
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE 21
FUSE, FUSIBLE LINK BLOCK (AT RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK F
GND POWER
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
LIFTING
LIFTING MOTOR (REAR) LIFTING MOTOR (FRONT)
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
P RANGE SW OR PKB SW PULSE SW (GND)
PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER)
PASSENGER COMPT FLOOR)
PNK 5 4 14 WIRE
PNK WIRE
POWER SEAT SWITCH
POWER WALK-IN RELAY
PPL
RECLINING
RECLINING MOTOR SLIDING SW (RR)
RED WIRE
RED/WHT WIRE
SEAT BACK SWITCH SLIDING SENSOR
SLIDING
SLIDING LIMIT SWITCH POWER WALK-IN SWITCH
SLIDING MOTOR
SLIDING MOTOR (RR) SLIDING MOTOR (FR) PULSE SW FORWARD SW
SLIDING SW (FR)
SPEED SIG
UNIFIED METER CONTROL UNIT
UP DN REAR
WALK-IN SW LIMIT SW (FORWARD)
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Power seats circuit, coupe (1 of 2) -> DRIVER SIDE DOOR SWITCH (ON LEFT FRONT SIDE OF
