Infiniti G35 III (2002-2007) driver side door switch Wiring diagrams

64 62 57 TRUNK LAMP OUT DOOR SW (DR) TRUNK SW BLK WIRE BLK/PNK WIRE BLU WIRE BLU/ORG WIRE DOOR DRIVER SIDE DOOR SWITCH FUSE 1 FUSE 18 FUSE 21 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE, FUSIBLE LINK BLOCK (AT RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK F GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION KEY HOLE ILLUMINATION KEY SWITCH LT GRN WIRE MAP LAMP OFF OFF VANITY MIRROR LAMP (DRIVER SIDE) (IF EQUIPPED) OFF VANITY MIRROR LAMP (PASSENGER SIDE) (IF EQUIPPED) ON ON OFF ORG/ WIRE PASSENGER SIDE DOOR SWITCH PNK WIRE POWER WINDOWS SYSTEM COMPUTER DATA LINES SYSTEM PPL PPL PNK WIRE PPL/RED WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE STEP LAMP (DRIVER SIDE) STEP LAMP (PASSENGER SIDE) TRUNK ROOM LAMP TRUNK ROOM LAMP SWITCH (AT CENTER REAR OF TRUNK LID) WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/PPL WIRE

39 40 CAN-H CAN-L PNK WIRE 52 55 42 GND BAT (F/L) BAT (FUSE) 54 53 PWR SUPPLY PWR SUPPLY BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BODY CONTROL MODULE (BEHIND LEFT KICK PANEL) CLOSED OPEN COMBINATION METER DOOR SW (DR) DRIVER SIDE DOOR SWITCH FUSE 1 FUSE 18 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE, FUSIBLE LINK BLOCK (AT RIGHT REAR OF ENGINE COMPARTMENT) FUSIBLE LINK F GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IGN PASSENGER SIDE DOOR SWITCH PNK 5 4 14 WIRE PNK COMPUTER DATA LINES SYSTEM WIRE PNK DOOR SW (AS) WIRE RED WIRE SUN ROOF MOTOR ASSEMBLY (AT CENTER FRONT OF ROOF) SUN ROOF SWITCH TILT DOWN/ SLIDE OPEN TILT UP/ SLIDE CLOSE TIMER (+IGN) GROUND UNIFIED METER CONTROL UNIT WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 BAT 3 4 ENCODER 38 39 40 22 IGNITION SW CAN-H CAN-L PWR WDO SERIAL LINK 4 5 PNK WIRE 52 55 54 42 53 GND BAT PWR WDO PWR SUPPLY BAT PWR WDO PWR SUPPLY BCM (BODY CONTROL MODULE) (BEHIND LEFT KICK PANEL) BETWEEN FULL STROKE, N FULL STROKE BLK WIRE BLU WIRE BRN WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM DOOR SW (DR) DOWN UP DRIVER SIDE DOOR SWITCH DRIVER SIDE POWER WINDOW MOTOR (AT CENTER OF DRIVER DOOR) ENCODER FULL CLOSED FUSE 1 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE 18 FUSE, FUSIBLE LINK, RELAY BOX (AT RIGHT REAR OF ENGINE COMPT) FUSIBLE LINK F GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START ILLUMINATION LIMIT SW PWR WINDOW SERIAL LINK LIMIT SWITCH LIMIT SWITCH FULL CLOSED PPL LOCK SWITCH LT BLU WIRE LT GRN WIRE OPEN PASSENGER SIDE FRONT DOOR SWITCH ORG/ WIRE OTHER PASSENGER SIDE POWER WINDOW MOTOR (AT CENTER OF FRONT PASSENGER DOOR) PNK DOOR SW (AS) WIRE PNK WIRE POWER WINDOW LOCK SWITCH POWER WINDOW MAIN SWITCH POWER WINDOW SUB-SWITCH PPL PPL ENCODER, LIMIT SW GND ENCODER PWR RED WIRE UNIFIED METER CONTROL UNIT UNLOCK LOCK UNLOCK SWITCH UP DOWN BAT GND PULSE WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE
