Infiniti G35 III (2002-2007) display and a/c temp amp Wiring diagram
This page shows the only wiring diagram for the component.display and a/c temp amp, which is found in the car Infiniti G35 III (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram display and a/c temp amp (1 of 1)
1 2 3 PS GND PS SIGNAL
8 9 10 PNK WIRE
BELT TENSION SENSOR (AT LOWER RIGHT"B: PILLAR)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN/WHT WIRE
BTS GND BTS SIGNAL
DISPLAY AND A/C TEMP AMP
FRONT PASSENGER AIR BAG MODULE
GRN WIRE
GRN/BLK WIRE
LEFT SIDE AIR BAG (SATELLITE) SENSOR (AT BASE OF LEFT "B" PILLAR)
LEFT SIDE CURTAIN AIR BAG MODULE
LT GRN/BLK WIRE
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM CONTROL (UNDER FRONT PASSENGER'S SEAT)
ORG/ WIRE
PNK WIRE
RED WIRE
RED/WHT WIRE
RIGHT SIDE AIR BAG (SATELLITE) SENSOR (AT BASE OF RIGHT "B" PILLAR)
RIGHT SIDE CURTAIN AIR BAG MODULE
SEAT PRESSURE SENSOR (UNDER RIGHT FRONT SEAT)
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> DISPLAY AND A/C TEMP AMP
