Infiniti G35 III (2002-2007) cancel off switch Wiring diagram
This page shows the only wiring diagram for the component.cancel off switch, which is found in the car Infiniti G35 III (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cancel off switch (1 of 1)
3 1 (COUPE) (SEDAN)
A/T M/T
ACCEL/ OFF RESUME SWITCH
ASCD BRAKE SWITCH (ON BRAKE PEDAL BRACKET)
ASCD CLUTCH SWITCH (SEDAN: ON CLUTCH PEDAL BRACKET)
ASCD STEERING SWITCH
AVCC 2 MOTOR 1
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/ORG WIRE
BRN WIRE
CAN L
CANCEL OFF SWITCH
CLOSE
COAST/ OFF SET SWITCH
COMBINATION METER
COMBINATION SWITCH (SPIRAL CABLE)
CRUISE IND (GREEN)
ECM RELAY
ENGINE CONTROL MODULE (ECM) (BEHIND GLOVE BOX)
ENGINE CONTROLS SYSTEM
FUSE 1
FUSE 12
FUSE 14
FUSE 19
FUSE 20
FUSE 34
FUSE 77 FUSE 87
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK, RELAY BOX (AT RIGHT REAR OF ENGINE COMPARTMENT)
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
MOTOR 2
MOTOR ELECTRIC THROTTLE CONTROL ACTUATOR (ON THROTTLE BODY ASSEMBLY)
NCA WIRE
ON/OFF OFF (MAIN) SWITCH
PNK 14 6 DATA LINK CONNECTOR (DLC) (LOWER LEFT SIDE OF DASH) WIRE
PNK PNK WIRE
PNK VB VB PNK PNK WIRE
PNK WIRE
PNK/BLU WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
SEDAN 2 4 COUPE PNK/ WIRE
SENSOR
SENSOR 1
SENSOR 2
SET IND
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
THROTTLE CONTROL
THROTTLE POSITION
TPS 2 TPS 1
UNIFIED METER CONTROL UNIT
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Cruise control circuit -> CANCEL OFF SWITCH
