Infiniti G35 III (2002-2007) buckle sw as Wiring diagram
This page shows the only wiring diagram for the component.buckle sw as, which is found in the car Infiniti G35 III (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram buckle sw as (1 of 1)
BACK- WARD
BACKWARD
BAT (F/L)
BAT FUSE
BATT (PTC)
BATT FUSE
BLK WIRE
BLK/RED WIRE
BLU WIRE
BODY CONTROL MODULE (BEHIND LEFT KICK PANEL)
BRN WIRE
BUCKLE SW AS
DOOR SW (AS)
FOR- WARD
FORWARD SW
FORWARD/
GND POWER
GRY WIRE
LIMIT SW (FORWARD)
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PASSENGER SEAT CONTROL UNIT
PASSENGER SIDE DOOR SWITCH
PASSENGER SIDE SEAT BELT BUCKLE SWITCH (IN FRONT PASSENGER SEAT BELT BUCKLE)
PNK WIRE
POWER SEAT SWITCH
POWER WALK-IN SWITCH
PULSE SW (GND) PULSE SW
PWR WINDOW PWR SUPPLY (BAT)
RECLINING MOTOR
RECLINING SWITCH
RED WIRE
RED/WHT WIRE
SEAT BACK SWITCH
SLIDING LIMIT SWITCH
SLIDING MOTOR (RR) SLIDING MOTOR (FR)
SLIDING MOTOR SLIDING SENSOR
SLIDING SW (FR)
SLIDING SW (RR)
SLIDING SWITCH
SPEED SIG
WALK IN SW
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Power seats circuit, coupe (2 of 2) -> BUCKLE SW AS
