Infiniti G35 III (2002-2007) 6 2 3 ign sw can-h can-l Wiring diagram
This page shows the only wiring diagram for the component.6 2 3 ign sw can-h can-l, which is found in the car Infiniti G35 III (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 6 2 3 ign sw can-h can-l (1 of 1)
1/2
11 12 BAT GND
6 2 3 IGN SW CAN-H CAN-L
7 27 1 32 31 KEY SW PUSH SW
94 86 CAN-H CAN-L PNK WIRE
BAT (F/L) BAT (FUSE) GND
BLK WIRE
BLK/PNK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (BEHIND LEFT KICK PANEL)
BRN WIRE
CAN-H CAN-L PNK WIRE
DATA LINK COMPUTER CONNECTOR DATA LINES (LOWER LEFT SYSTEM SIDE OF DASH)
EARTH
ENGINE CONTROL MODULE (ECM) (BEHIND GLOVE BOX)
FUSE 1
FUSE 12
FUSE 18
FUSE 19
FUSE 33
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BOX
FUSIBLE LINK F
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IGN SW SECURITY IND OUT KEY SW
IGNITION KNOB SWITCH
INSERTED REMOVED
INTELLIGENT KEY UNIT (BEHIND RIGHT SIDE OF DASH)
KEY SWITCH
KEY SWITCH, IGNITION KNOB SWITCH
NATS ANTENNA AMPLIFIER (BEHIND LEFT SIDE OF DASH)
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
RED WIRE
SECURITY INDICATOR LAMP
SIG GND
SIGNAL
STEERING LOCK UNIT (NEAR STEERING COLUMN)
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WITH- DRAWN PUSHED
YEL WIRE
YEL/GRN WIRE
Go to component -> Immobilizer circuit (nats), with intelligent key unit -> 6 2 3 IGN SW CAN-H CAN-L
