Infiniti G35 III (2002-2007) 5 6 7 8 9 10 ant signal back-up Wiring diagram

1 2 3 4 BACK UP WOOFER OUT (-) WOOFER OUT (-) 11 12 GND AMP ON SIGNAL 13 14 RR SP LH (-) AMP RR SP LH (+) AMP 15 16 PNK RR SP RH (-) AMP RR SP RH (+) AMP WIRE 17 18 19 20 GROUND WOOFER OUT (+) WOOFER OUT (+) 3 4 FR SP RH (-) AMP FR SP RH (+) AMP 5 6 7 8 9 10 ANT SIGNAL BACK-UP ANT MAIN ANT SIG ANT SIGNAL FR SP LH (-) AMP FR SP LH (+) AMP 1 2 AUDIO UNIT BLK WIRE BLK/PNK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BOSE SPEAKER AMPLIFIER (AT LEFT REAR OF TRUNK) BRN WIRE COMBINATION METER COMBINATION SWITCH DATA GND RX TX DOWN DRIVER DOOR SPEAKER DRIVER SIDE TWEETER FEEDER CABLE ANT SIGNAL FUSE 37 FUSE 6 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE, FUSIBLE LINK BOX GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON ILLUM LEFT REAR SPEAKER LEFT WOOFER LIGHTING SWITCH EARTH LT BLU WIRE LT GRN WIRE MODE NAVI IN (-) NAVI GND NAVI IN (+) NAVIGATION SYSTEM NCA WIRE OFF OFF ON OPTION CONNECTOR (FOR SATELLITE RADIO RECEIVER) ORG/ WIRE ORG/BLU WIRE PASSENGER DOOR SPEAKER PASSENGER SIDE TWEETER POWER PPL RED WIRE RED/BLK WIRE RED/BLU WIRE REM CONTROL A REM CONTROL B NAVI ON REM CONTROL GND RIGHT REAR SPEAKER RIGHT WOOFER SEEK SPEED SIGNAL STEERING WHEEL/ AUDIO CONTROL SWITCH SWITCH UNIFIED METER CONTROL UNIT VOLUME- WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WINDOW ANTENNA (MAIN) WINDOW WINDOW ANTENNA ANTENNA (SUB) YEL WIRE YEL/RED WIRE
