Heated seats circuit, sedan for Infiniti G25 IV facelift (2006-2013)

17 18 HEAT SENSOR 70 71 HEAT SENSOR A/T W/O MEMORY BLK WIRE BLU WIRE BLU/WHT WIRE BRN WIRE DRIVER SIDE FRONT SEAT DRIVER SIDE HEATED SEAT SWITCH FUSE 3 FUSE 35 FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE, FUSIBLE LINK BLOCK GRN WIRE GRY WIRE HEATED SEAT CONTROL UNIT HEATED SEAT RELAY (BEHIND CENTER OF DASH) HEATER HEATER SW HOT AT ALL TIMES HOT IN ON OR START INDICATOR LT BLU WIRE LT GRN WIRE M/T M/T, A/T W/ MEMORY MAIN HEATER SEAT BACK HEATER MAIN SUB- HEATER HEATER NCA WIRE PASSENGER SIDE FRONT SEAT PASSENGER SIDE HEATED SEAT SWITCH PNK WIRE PPL RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE SEAT CUSHION HEATER SUB HEATER TAN WIRE THERMISTOR INPUT THERMISTOR OUTPUT WHT WIRE YEL WIRE
