Infiniti G25 IV facelift (2006-2013) sliding switch Wiring diagram
This page shows the only wiring diagram for the component.sliding switch, which is found in the car Infiniti G25 IV facelift (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sliding switch (1 of 1)
13 11 GND BAT (FUSE)
BACKWARD
BAT (F/L)
BCM (BODY CONTROL MODULE) (BEHIND RIGHT KICK PANEL)
BLK WIRE
BLU WIRE
CIRCUIT BREAKER (BEHIND CENTER OF DASH)
DOWN
DRIVER SIDE FRONT POWER SEAT
FORWARD/
FRONT LIFTING MOTOR
FRONT LIFTING MOTOR (8-WAY)
FRONT LIFTING SWITCH
FUSE
FUSE 10 BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BLOCK
FUSIBLE LINK K
GRN WIRE
HOT AT ALL TIMES
PASSENGER SIDE FRONT POWER SEAT
PNK WIRE
POWER SEAT SWITCH
POWER SPLY (BAT)
PPL
REAR LIFTING MOTOR
REAR LIFTING MOTOR (8-WAY)
REAR LIFTING SWITCH
RECLINING MOTOR
RECLINING SWITCH
RED WIRE
SLIDING MOTOR
SLIDING SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power seats circuit, sedan -> SLIDING SWITCH
