Infiniti G25 IV facelift (2006-2013) side marker tail/ stop Wiring diagram
This page shows the only wiring diagram for the component.side marker tail/ stop, which is found in the car Infiniti G25 IV facelift (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram side marker tail/ stop (1 of 1)
11 13 BAT (FUSE) GND
124 150 PASS DR SW DRV DR SW
17 18 FRONT TURN SIG (RIGHT) FRONT TURN SIG (LEFT)
20 25 PPL REAR TURN SIG (RIGHT) REAR TURN SIG (LEFT)
53 54 55 71 56 72 IGN BAT GND GND CAN-H CAN-L
68 69 RR DR SW LR DR SW
7 27 COMM (AMP-METER) COMM (METER-AMP)
91 90 CAN-H CAN-L PNK WIRE
BAT (F/L)
BCM (BODY CONTROL MODULE) (BEHIND RIGHT KICK PANEL)
BLK WIRE
BLU WIRE
BRN WIRE
CENTER REAR OF LUGGAGE COMPT)
COMBINATION METER
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
COUPE, SEDAN
FUSE 10
FUSE 11
FUSE 3
FUSE BLOCK (J/B) (BEHIND LEFT
GRN WIRE
GRY WIRE
HAZARD ON
HAZARD SW
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE, FUSIBLE LINK BLOCK FUSIBLE LINK K
HOT IN ON OR START
KICK PANEL)
LAMP
LEFT LICENSE PLATE
LEFT REAR COMBINATION LAMP
LT BLU WIRE
LT GRN WIRE
MULTI-FUNCTION SWITCH (HAZARD SWITCH)
NCA WIRE
PNK WIRE
PPL
RED WIRE
RIGHT LICENSE PLATE
RIGHT REAR COMBINATION LAMP
SIDE MARKER TAIL/ STOP
SIDE MARKER TAIL/ STOP/ TURN
TAN WIRE
TURN
TURN IND
UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER OF DASH)
W/ DAYTIME RUNNING LIGHT SYSTEM
W/O DAYTIME RUNNING LIGHT SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 3) -> SIDE MARKER TAIL/ STOP
