Infiniti G25 IV facelift (2006-2013) shift lock unit shift lock Wiring diagrams
This page contains all the electrical diagrams for the component. shift lock unit shift lock, in which he is found in the car Infiniti G25 IV facelift (2006-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram shift lock unit shift lock (1 of 2)
1 2 PPL
A/T SHIFT SELECTOR
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT KICK PANEL)
BRN WIRE
COMPUTER DATA LINES SYSTEM W/ ICC
FUSE 3 (BEHIND LEFT KICK PANEL)
FUSE 7
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ICC BRAKE HOLD RELAY (W/ ICC) (LEFT SIDE OF ENGINE COMPT)
ICC SENSOR INTEGRATED UNIT (W/ ICC) (LEFT FRONT OF ENGINE COMPT)
LT BLU WIRE
PNK 90 91 96 COMPUTER DATA LINES SYSTEM CAN-L CAN-H A/T SHIFT WIRE
PNK WIRE
PPL
PPL PNK 2 6 3 SIG CAN-L CAN-H WIRE
SELECTOR LEVER POSITION INDICATOR
SHIFT LOCK RELAY (W/ ICC) (RIGHT REAR OF ENGINE COMPT)
SHIFT LOCK UNIT SHIFT LOCK
SHIFT POSITION SWITCH
SOLENOID
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
W/O ICC W/ ICC
WHT WIRE
Go to component -> Shift interlock circuit, convertible -> SHIFT LOCK UNIT SHIFT LOCK
Wiring diagram shift lock unit shift lock (2 of 2)
2 6 3 (OR PPL) PNK WIRE
A/T SHIFT
A/T SHIFT SELECTOR
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (BEHIND RIGHT KICK PANEL)
BRN WIRE
COMPUTER DATA LINES SYSTEM PPL
COUPE
FUSE 3 (BEHIND LEFT KICK PANEL)
FUSE 7
FUSE BLOCK (J/B)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ICC BRAKE HOLD RELAY (W/ ICC) (LEFT SIDE OF ENGINE COMPT)
ICC SENSOR INTEGRATED UNIT (W/ ICC) (LEFT FRONT OF ENGINE COMPT)
LT BLU WIRE
LT GRN WIRE
PNK 90 91 96 CAN-L CAN-H WIRE
PPL
SELECTOR LEVER POSITION INDICATOR
SHIFT LOCK RELAY (W/ ICC) (RIGHT REAR OF ENGINE PPL PPL COMPT)
SHIFT LOCK UNIT SHIFT LOCK
SHIFT POSITION SWITCH
SIG CAN-L CAN-H
SOLENOID
STOP LAMP SWITCH (W/ ICC)
STOP LAMP SWITCH (W/O ICC) (ON BRAKE PEDAL BRACKET)
W/O ICC W/ ICC (LEFT REAR OF ENGINE COMPT)
WHT WIRE
Go to component -> Shift interlock circuit, except convertible -> SHIFT LOCK UNIT SHIFT LOCK
