Infiniti G25 IV facelift (2006-2013) set memory switch switch Wiring diagram
This page shows the only wiring diagram for the component.set memory switch switch, which is found in the car Infiniti G25 IV facelift (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram set memory switch switch (1 of 1)
A/T M/T
A/T SHIFT BRAKE LEVER ASSEMBLY) SELECTOR (DETENSION SWITCH)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CHANGE OVER SWITCH
CIRCUIT BREAKER
CUSHION SIDE DEFLATE SOLENOID
CUSHION SIDE INFLATE SOLENOID
DEFLATE CUSHION SIDE
DRIVER SIDE FRONT SEAT SIDE SUPPORT UNIT
GRN WIRE
GRY WIRE
IND 2 MEMORY
INFLATE
INFLATE DEFLATE SEAT BACK SIDE
LEFT
LT BLU WIRE
LT GRN WIRE
MEMORY IND 1
MEMORY SWITCH
MIRROR SWITCH DOOR MIRROR REMOTE CONTROL SWITCH
OFF
ON ON OFF OFF
PARKING BRAKE SWITCH (BASE OF PARKING
PNK WIRE
PPL
PPL/WHT WIRE
PUMP
PUMP RELAY
RED WIRE
RIGHT
SEAT BACK SIDE DEFLATE SOLENOID
SEAT BACK SIDE INFLATE SOLENOID
SEAT MEMORY SWITCH
SET MEMORY SWITCH SWITCH
SIDE SUPPORT SWITCH
TAN WIRE
UP DN OFF
WHT WIRE
YEL WIRE
Go to component -> Memory systems circuit, sedan (2 of 3) -> SET MEMORY SWITCH SWITCH
