Infiniti G25 IV facelift (2006-2013) sens output 2 sens gnd can-l Wiring diagram
This page shows the only wiring diagram for the component.sens output 2 sens gnd can-l, which is found in the car Infiniti G25 IV facelift (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sens output 2 sens gnd can-l (1 of 1)
1 2 3 4 RH MOTOR (RE) +B RH MOTOR (FN) LH MOTOR (FN)
3 2 24 25 21 30 29 AMP-METER METER-AMP LCD-AMP AMP-LCD IGN SIGNAL SW SIG SW
3 8 3 8 CAN-H CAN-L
5 6 GND (DRIVE) LH MOTOR (RE)
53 56 72 55 IGN PWR SPLY CAN-H CAN-L GND
7 8 9 INDICATOR RH BUCKLE SW
9 34 14 27 7 SW SIGNAL AMP-LCD LCD-AMP METER-AMP AMP-METER
A/T ASSEMBLY (AT REAR OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BRAKE PEDAL STROKE SENSOR
BRN WIRE
CAN-H
CAN-H CAN-L PNK WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM PNK WIRE
EXCEPT CONVERTIBLE CONVERTIBLE
FUSE 1
FUSE 3
FUSE 4
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BLOCK
FUSIBLE LINK G
GND (CONT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ICC SENSOR INTEGRATED UNIT (LEFT FRONT OF ENGINE COMPT)
IGN
LEFT PRE CRASH SEAT BELT MOTOR
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PRE-CRASH SEAT BELT CONTROL UNIT (BEHIND RIGHT END OF DASH)
RED WIRE
RIGHT PRE CRASH SEAT BELT MOTOR
SEAT BELT
SEAT BELT BUCKLE SWITCH (DRIVER SIDE) (IN DRIVER SEAT BELT BUCKLE ASSEMBLY)
SENS OUTPUT 1
SENS OUTPUT 2 SENS GND CAN-L
SENS POWER
SW INPUT
TRANSMISSION CONTROL MODULE
UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER OF DASH)
VCC
WHT WIRE
YEL WIRE
Go to component -> Passive restraints circuit -> SENS OUTPUT 2 SENS GND CAN-L
