Infiniti G25 IV facelift (2006-2013) rev lamp rly Wiring diagrams
This page contains all the electrical diagrams for the component. rev lamp rly, in which he is found in the car Infiniti G25 IV facelift (2006-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rev lamp rly (1 of 3)
17 18 R RANGE SIG K-LINE PPL COMPUTER DATA LINES SYSTEM
A/T ASSEMBLY (AT REAR OF ENGINE COMPT)
AV CONTROL UNIT
BACK-UP
BACKUP LIGHT RELAY (BEHIND CENTER OF DASH)
BLK WIRE
BLU WIRE
CENTER REAR OF LUGGAGE COMPT)
EXCEPT SEDAN
FUSE 4
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
HOT IN ON OR START
JOINT CONNECTOR
LEFT BACKUP LAMP
LEFT REAR COMBINATION LAMP
LT GRN WIRE
RED WIRE
REV LAMP RLY
REVERSE
RIGHT BACKUP LAMP
RIGHT REAR COMBINATION LAMP
SEDAN
SONAR CONTROL UNIT
TAN WIRE
TCM (TRANSMISSION CONTROL MODULE)
TRANSMISSION RANGE SWITCH
WHT WIRE
Go to component -> Backup lamps circuit -> REV LAMP RLY
Wiring diagram rev lamp rly (2 of 3)
1 2 138 139 AM-FM MAIN ANTENNA AMP ON SIG
14 9 3 8 6 1 PPL EJECT SIG SW GND
A/T
AM-FM MAIN
AMP ON SIG
ANTENNA AMP
AUX IMAGE GND
AUX IMAGE SIG
AUXILIARY INPUT JACKS
AV COMM (L) AV COMM (H) GND
AV CONTROL UNIT
BACKUP LAMP RELAY (BEHIND CENTER OF DASH)
BACKUP LAMP SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMPUTER DATA LINES SYSTEM
COUPE
FM SUB
FUSE 3
GLASS ANTENNA (MAIN) (SEDAN) WINDOW ANTENNA (MAIN) (COUPE)
GLASS ANTENNA (SUB)
GND CAN-H CAN-L AV COMM (H) AV COMM (L) AV COMM (H) AV COMM (L)
GRN (OR LT GRN) WIRE
GRN WIRE
HOT W/ IGNITION RELAY ENERGIZED
HOT W/ IGNITION RELAY ENERGIZED FUSE BLOCK (J/B) FUSE 4 (BEHIND LEFT KICK PANEL)
LH SOUND SIG (-)
LT BLU WIRE
LT GRN WIRE
M/T
MULTI- FUNCTION SWITCH
NCA WIRE
ORG/ WIRE
PARKING BRAKE SWITCH
PNK WIRE
PPL EJECT SIG IGNITION REVERSE PARKING BRAKE VEHICLE SPEED
RED OR LT GRN WIRE
RED WIRE
REV LAMP RLY
RH AUX SOUND SIG (+) LH AUX SOUND SIG (+) SHIELD
RH SOUND SIG (+)
SHIELD
SHIELD SHIELD AUX IMAGE GND
SIG GROUND
SPEED
SW GND
TAN WIRE
TCM A/T ASSEMBLY (AT REAR OF ENGINE COMPT)
UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER OF DASH)
WHT WIRE
Go to component -> Base radio circuit, without rear view camera (3 of 3) -> REV LAMP RLY
Wiring diagram rev lamp rly (3 of 3)
1 2 AMP ON SIG AM-FM MAIN
132 133 134 135 136 USB GND USB D- SIG V BUS SIG USB D+ SIG SHIELD
3 2 1 137 138 139 FM SUB AM-FM MAIN ANTENNA AMP ON SIG
A/T
A/T ASSEMBLY (AT REAR OF ENGINE COMPT)
A/T M/T
ANTENNA
ANTENNA AMPLIFIER
AV COMM (H)
AV COMM (L)
AV CONTROL UNIT
BACKUP LAMP RELAY (BEHIND CENTER OF DASH)
BACKUP LAMP SWITCH
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
CAN L
CAN-H
COMM
COMPUTER DATA LINES SYSTEM
EJECT SIG
FUSE 4
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GLASS ANTENNA (MAIN)
GLASS ANTENNA (SUB)
GRN WIRE
GRY WIRE
HOT IN ON OR START
L SOUND SIG (+)
LR SOUND SIG (-) LF SOUND SIG (-)
LT BLU WIRE
LT GRN WIRE
M/T
MULTI- FUNCTION SWITCH
NCA WIRE
ORG/ WIRE
PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER ASSEMBLY) USB CONNECTOR
PNK SHIELD WIRE
PNK WIRE
PPL
R SOUND SIG (+)
RED OR LT GRN WIRE
RED WIRE
REQUEST
REV LAMP RLY
SATELLITE RADIO ANTENNA
SATELLITE RADIO TUNER (RIGHT REAR OF LUGGAGE COMPT)
SHIELD
SHIELD SHIELD
SHIELD SHIELD TEL VOICE SIG (+) TEL VOICE SIG (-)
SW GND
TAN WIRE
TCM (TRANSMISSION CONTROL MODULE)
UNIFIED METER, A/C AMPLIFIER (BEHIND CENTER OF DASH)
VEHICLE SPD
VEHICLE SPD PARKING BRAKE REVERSE IGN DISK EJECT SIG
WHT WIRE
YEL WIRE
Go to component -> Bose radio circuit, without navigation (4 of 4) -> REV LAMP RLY
