Infiniti G25 IV facelift (2006-2013) ppl computer data lines system Wiring diagram
This page shows the only wiring diagram for the component.ppl computer data lines system, which is found in the car Infiniti G25 IV facelift (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl computer data lines system (1 of 1)
3 2 BUS-H BUS-L
ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) (LEFT REAR OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BRN WIRE
BUS-H
BUS-L DP FL DS RL UZ DS RR BLS VDC OFF SW
CAN-H- CAN-L-
COMPUTER DATA LINES PNK 2 8 7 SYSTEM IGN GND WIRE
COMPUTER DATA LINES SYSTEM CAN-H
COUPE CONVERTIBLE
DP FR DS FR DIAG-K
EXCEPT CONVERTIBLE
FUSE 45
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
FUSE, FUSIBLE LINK BLOCK
FUSIBLE LINK L
FUSIBLE LINK M
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ILL
LEFT FRONT WHEEL SENSOR
LEFT REAR WHEEL SENSOR
LT BLU WIRE
LT GRN WIRE
PNK CAN-L WIRE
PNK WIRE
PPL
PPL COMPUTER DATA LINES SYSTEM
RED WIRE
RESISTOR
RIGHT FRONT WHEEL SENSOR
RIGHT REAR WHEEL SENSOR
SEDAN
STEERING ANGLE SENSOR (UNDER LEFT SIDE OF DASH)
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
TAN WIRE
VDC OFF SWITCH
WHT WIRE
YAW RATE/ SIDE G SENSOR (UNDER CENTER CONSOLE)
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> PPL COMPUTER DATA LINES SYSTEM
