Infiniti G25 IV facelift (2006-2013) ppl 30 14 34 27 7 brake sw lcd amp amp lcd meter amp amp meter Wiring diagram
This page shows the only wiring diagram for the component.ppl 30 14 34 27 7 brake sw lcd amp amp lcd meter amp amp meter, which is found in the car Infiniti G25 IV facelift (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl 30 14 34 27 7 brake sw lcd amp amp lcd meter amp amp meter (1 of 1)
71 55 53 41 54 56 72 57 GND GND IGN
A/T
BAT CAN-H CAN-L LEVEL SW
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH (LEFT REAR OF ENGINE COMPT)
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
COUPE
EXCEPT CONVERTIBLE
FUSE 11
FUSE 19
FUSE 3
FUSE 4
FUSE 7
FUSE BLOCK (J/B)
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
PARKING BRAKE SWITCH
PNK WIRE
PPL
PPL 30 14 34 27 7 BRAKE SW LCD AMP AMP LCD METER AMP AMP METER
PPL M/T
RED WIRE
RESISTOR
SEDAN
SHIFT INTERLOCK SYSTEM
STOP LAMP SWITCH (ON BRAKE PEDAL BRACKET)
TAN WIRE
UNIFIED METER, A/C AMPLIFIER
W/O ICC W/ ICC
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> PPL 30 14 34 27 7 BRAKE SW LCD AMP AMP LCD METER AMP AMP METER
