Infiniti G25 IV facelift (2006-2013) cont ill Wiring diagram
This page shows the only wiring diagram for the component.cont ill, which is found in the car Infiniti G25 IV facelift (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cont ill (1 of 1)
A/T
A/T SHIFT SELECTOR ILLUMINATION
AV CONTROL UNIT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CIGARETTE LIGHTER SOCKET ILLUMINATION (M/T)
CLOCK (ILLUMINATION)
COMBINATION SWITCH (SPIRAL CABLE) (IN STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
CONT ILL
DOOR MIRROR REMOTE CONTROL SWITCH (ILLUMINATION)
DRIVER SIDE HEATED SEAT SWITCH (ILLUMINATION)
FUSE 50
FUSE 51
FUSE 53
FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL)
GLOVE BOX LAMP (ILLUMINATION)
GRN WIRE
HOT AT ALL TIMES
ILL
ILLUM
LT BLU WIRE
LT GRN WIRE
M/T
MAP LAMP ILLUMINATION
MULTI- FUNCTION SWITCH ILLUMINATION
NCA WIRE
PASSENGER SIDE HEATED SEAT SWITCH (ILLUMINATION)
PNK WIRE
RED WIRE
SELECTOR LEVER POSITION INDICATOR
SHIFT POSITION SWITCH
SNOW MODE SWITCH (ILLUMINATION) (W/AWD)
SONAR CANCEL SWITCH (ILLUMINATION) (IF EQUIPPED)
STEERING SWITCH ILLUMINATION
TAIL LAMP RELAY
TAN WIRE
TRUNK LID OPENER SWITCH (ILLUMINATION)
VDC OFF SWITCH ILLUMINATION
W/ NAVIGATION
W/O NAVIGATION, REAR VIEW MONITOR W/O NAVIGATION, W/ REAR VIEW MONITOR
YEL WIRE
Go to component -> Instrument illumination circuit (2 of 2) -> CONT ILL
