Infiniti G25 IV facelift (2006-2013) comm amp mtr Wiring diagram
This page shows the only wiring diagram for the component.comm amp mtr, which is found in the car Infiniti G25 IV facelift (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram comm amp mtr (1 of 1)
AMP
AMP-LCD
BLK WIRE
BLU WIRE
BRN WIRE
CAMSHAFT POSITION SENSOR (PHASE) (BANK 2) (FRONT OF CYLINDER BANK 2)
CAN L
CAN-H
CANISTER)
COMBINATION METER
COMM AMP LCD
COMM AMP MTR
COMM LCD AMP
COMM-MTR->AMP
COMPUTER DATA LINES SYSTEM
EVAP CANISTER VENT CONTROL VALVE (ON EVAP
GRN WIRE
GRY WIRE
IGN
LCD
LT BLU WIRE
LT GRN WIRE
METER
PNK PPL PPL WIRE
PNK WIRE
POWER STEERING PRESSURE SENSOR (RIGHT FRONT OF ENGINE)
RED WIRE
SENS GND
SW SIG
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.5l (4 of 5) -> COMM AMP MTR
