Infiniti G25 IV facelift (2006-2013) bat ign can-h can-l Wiring diagram

1 2 3 BAT METER-AMP AMP-METER 14 34 28 30 27 7 LCD-AMP AMP-LCD SPD (8-PULSE) PRK BRAKE SW METER-AMP AMP-METER 18 18 18 100 57 100 PPL (OR PNK) WIRE 3.7L 2.5L 39 40 PNK COMPUTER DATA LINES SYSTEM WIRE 4 3 BAT GND 42 58 41 54 53 56 72 FUEL LVL SENS FUEL LVL GND 57 45 61 BRK FLUID SW AMB SENS AMB SENS GND PPL 6 10 8 IGN BAT GND 90 91 PNK CAN-L CAN-H WIRE A/T M/T M/T A/T AMBIENT SENSOR BEHIND CENTER OF FRONT BUMPER AUTO ANTI-DAZZLING INSIDE MIRROR (COMPASS) BAT IGN CAN-H CAN-L BCM (BODY CONTROL MODULE) (BEHIND RIGHT KICK PANEL) BLK WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH BRN WIRE CLOCK COMBINATION METER COMPUTER DATA LINES SYSTEM CONVERTIBLE, COUPE SEDAN DISTRIBUTION MODULE ENGINE ROOM) (AT RIGHT REAR OF ENGINE COMPT) ENTER FUEL LEVEL SENSOR UNIT (SUB) FUSE 11 FUSE 19 (BEHIND LEFT KICK PANEL) FUSE 3 FUSE 4 FUSE 6 FUSE BLOCK (J/B) GND ACT SIG AIRBAG SIG GND METER CTRL SW GND GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START ILL ILL GND ILL GND ILL IGN GND ILLUMINATION CONTROL SWITCH INTERIOR LIGHTS SYSTEM ILL CTRL IPDM E/R (INTELLIGENT POWER LT BLU WIRE LT GRN WIRE METER CONTROL SWITCH OIL PRESSURE SWITCH PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER ASSEMBLY) PNK 8 7 12 8 7 12 19 20 18 WIRE PNK WIRE PPL PPL (OR PNK) WIRE RED WIRE SECURITY IND LP SECURITY SIG SEDAN CONVERTIBLE COUPE SEDAN COUPE, CONVERTIBLE SELECT SELECT SW ENTER SW TRIP A/B RESET SW ILL CTRL SW (-) ILL CTRL SW (+) STARTING/CHARGING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM TAN WIRE TRIP A/B RESET SWITCH TRIP COMPUTER SWITCH UNIFIED METER, A/C AMPLIFIER WARNING SYSTEMS WHT WIRE YEL WIRE
