Infiniti G25 IV facelift (2006-2013) 4 1 2 mic vcc mic sig mic gnd Wiring diagram
This page shows the only wiring diagram for the component.4 1 2 mic vcc mic sig mic gnd, which is found in the car Infiniti G25 IV facelift (2006-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 4 1 2 mic vcc mic sig mic gnd (1 of 1)
18 19 PNK WIRE
28 29 SHIELD
4 1 2 MIC VCC MIC SIG MIC GND
AV COMM (H)
AV COMM (L)
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION SWITCH (SPIRAL CABLE) (IN STEERING COLUMN)
COMM
COMPUTER DATA LINES SYSTEM
CONTROL SIG
DISPLAY UNIT
GRN WIRE
GRY WIRE
IGN
ILLUM
IMAGE GND
IMAGE SIG
INVERTER GND
INVERTER VCC
LT BLU WIRE
LT GRN WIRE
MENU DOWN
MENU SOURCE UP
MICROPHONE
MICROPHONE GND
MICROPHONE SIG
MICROPHONE VCC
NCA WIRE
PNK SHIELD WIRE
PNK WIRE
PPL
RED WIRE
RGB AREA SIG
RGB SIG
RGB SYNC
SHIELD
SHIELD SHIELD
SIG GND
SIGNAL VCC
STEERING SWITCH
TAN WIRE
TEL ADAPTER UNIT
TEL ANTENNA
TEL VOICE SIG -
TELEPHONE END
TELL ANTENNA
VEHICLE SPD
VOICE/ VOLUME DOWN TELEPHONE
VOLUME UP
WHT WIRE
YEL WIRE
Go to component -> Bose radio circuit, without navigation (2 of 4) -> 4 1 2 MIC VCC MIC SIG MIC GND
