Infiniti G25 IV facelift (2006-2013) 14 34 comm lcd comm amp lcd Wiring diagram

14 34 COMM LCD COMM AMP LCD 2346 BRAKE SOLENOID VALVE 24 3 2 COMM LCD AMP COMM AMP COMM METER 27 7 COMM METER COMM SIG 3.7L SEDAN 2.5L SEDAN EXCEPT SEDAN 53 41 54 56 72 IGN 55 71 GND GND A/T ASSEMBLY (AT REAR OF ENGINE COMPT) A/T FLUID TEMPERATURE SENSOR A/T SHIFT SELECTOR ANTI- INTERLOCK SOLENOID VALVE AUTO BAT CAN-H CAN-L BCM (BODY CONTROL MODULE) (BEHIND RIGHT KICK PANEL) BLK WIRE BLU WIRE BRN WIRE COMBINATION METER COMM AMP LCD COMPUTER DATA LINES SYSTEM DIRECT CLUTCH SOLENOID VALVE FRONT BRAKE SOLENOID VALVE FUSE 11 FUSE 19 GRN WIRE GRY WIRE HIGH, LOW REVERSE CLUTCH SOLENOID VALVE HOT AT ALL TIMES HOT AT ALL TIMES FUSE, FUSE 36 FUSIBLE LINK BLOCK HOT IN ACC OR ON HOT W/ IGNITION RELAY ENERGIZED FUSE BLOCK (J/B) (BEHIND LEFT KICK PANEL) FUSE 3 ILL INPUT CLUTCH SOLENOID VALVE INPUT SPEED SENSOR 1 INPUT SPEED SENSOR 2 JOINT CONNECTOR LINE PRESSURE SOLENOID VALVE LOW BRAKE SOLENOID VALVE LT BLU WIRE LT GRN WIRE MAN MODE SELECT SWITCH NCA WIRE ORG/ WIRE OUTPUT SPEED SENSOR PADDLE SHIFTER (SHIFT DOWN) (IF EQUIPPED) PADDLE SHIFTER (SHIFT-UP) (IF EQUIPPED) PNK WIRE POSITION SELECT SWITCH UP DN PPL PWR SPLY RED WIRE SELECT LEVER POSITION INDICATOR SHIFT POSITION SWITCH STARTING/ (RIGHT FRONT CHARGING OF ENGINE) SYSTEM SW 1 SW 2 SW 3 SW 4 TAN WIRE TCM (TRANSMISSION CONTROL MODULE) TORQUE CONVERTER CLUTCH SOLENOID VALVE TRANSMISSION RANGE SWITCH UNIFIED METER, A/C AMPLIFIER VIGN BATT CAN-H K-LINE GND VIGN REV LP RLY CAN-L STARTER RLY GND WHT WIRE YEL WIRE
