Car Wiring Diagrams for Courtesy lamps circuit for Infiniti G20 II (1999-2002)

BLK WIRE BLU WIRE CIRCUIT BREAKER 1 (BEHIND DASH, LEFT OF FUSE BLOCK) DIODE (TRUNK LAMP) (BEHIND RIGHT SIDE OF DASH, TAPED TO HARNESS) DRIVER SIDE FRONT DOOR LOCK ACTUATOR (UNLOCK SENSOR) DRIVER SIDE FRONT DOOR SWITCH DRIVER SIDE VANITY MIRROR LAMP FUSE 24 FUSE 8 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) GRN/RED WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON OR START INTERIOR ROOM LAMP DOOR OFF ON KEY SWITCH LEFT REAR DOOR SWITCH LT BLU WIRE MAP LAMP PASSENGER SIDE FRONT DOOR SWITCH PASSENGER SIDE VANITY MIRROR LAMP PNK PNK WIRE PNK WIRE RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT REAR DOOR SWITCH SMART ENTRANCE CONTRL UNIT (BEHIND DASH, LEFT OF STEERING COLUMN) TRUNK ROOM LAMP TRUNK ROOM LAMP SWITCH WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL/RED WIRE
