Car Wiring Diagrams for Anti-theft circuit for Infiniti G20 II (1999-2002)

BLK WIRE BRN/YEL WIRE CIRCUIT BREAKER 1 (BEHIND DASH, LEFT OF FUSE BLOCK) FUSE FUSE 10 FUSE 5 FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) FUSE 8 FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPARTMENT, NEXT TO BATTERY) GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE HOOD SWITCH (LEFT SIDE OF ENGINE COMPT) HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LT BLU WIRE LT GRN/RED WIRE ORG/ WIRE PNK WIRE POWER WINDOWS SYSTEM RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT FRONT FRONT DOOR DOOR SWITCH SWITCH RIGHT REAR DOOR SWITCH SECURITY INDICATOR LAMP SMART ENTRANCE CONTROL UNIT (BEHIND DASH, LEFT OF STEERING COLUMN) TRUNK ROOM LIGHT SWITCH WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE

BLK WIRE FULL STROKE FULL STROKE LOCK FULL STROKE UNLOCK FULL STROKE UNLOCK FULL STROKE LOCK FUSE 32 FUSE 33 FUSE 36 FUSE 41 FUSE, FUSIBLE LINK BOX GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE HEADLIGHTS SYSTEM HORN LOW HORN HIGH HORN RELAY (IN RELAY BOX) HOT AT ALL TIMES LEFT FRONT DOOR KEY CYLINDER SWITCH LEFT REAR DOOR LOCK ACTUATOR LOCKED LT GRN/RED WIRE MID STROKE ORG/ WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT DOOR KEY CYLINDER SWITCH RIGHT FRONT DOOR LOCK ACTUATOR RIGHT REAR DOOR LOCK ACTUATOR LEFT FRONT DOOR LOCK ACTUATOR THEFT WARNING LAMP RELAY VEHICLE SECURITY LAMP RELAY (IN RELAY BOX) (2000) TRUNK LID KEY CYLINDER SWITCH UNLOCKED YEL WIRE YEL/GRN WIRE YEL/RED WIRE
