Infiniti G20 II (1999-2002) throttle pos ground-c ignition switch Wiring diagram
This page shows the only wiring diagram for the component.throttle pos ground-c ignition switch, which is found in the car Infiniti G20 II (1999-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram throttle pos ground-c ignition switch (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 RELEASE VALVE
AIR VALVE
ASCD BRAKE SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
ASCD CLUTCH SWITCH (ON BRACKET, ABOVE CLUTCH PEDAL)
ASCD CONTROL UNIT (BEHIND DASH, LEFT OF STEERING COLUMN)
ASCD PUMP (RIGHT REAR CORNER OF ENGINE COMPT)
ASCD STEERING SWITCH
BLK WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BRAKE NC SW MAIN SWITCH IN PNK WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CANCEL SWITCH
CONTROL UNIT UNIFIED METER
CRUISE
FPC CONNECTOR
FUSE 11
FUSE 14
FUSE 36 FUSE 36 FUSE 41
FUSE 8
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
FUSE, FUSIBLE LINK BLOCK (LEFT FRONT OF ENG COMPT, NEXT TO BATTERY)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GROUND SET LAMP OUT
GRY WIRE
HORN RELAY (IN RELAY BOX)
HORN SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
LT BLU WIRE
MAIN SWITCH
NCA WIRE
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RELEASE VALVE
RESUME/ ACCEL SWITCH
SET-
SET/COAST SW ACTR OUT HIGH AIR VALVE LOW VACUUM MOTOR CRUISE LAMP
SET/COAST SWITCH
SPIRAL CABLE
STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
THROTTLE POS GROUND-C IGNITION SWITCH
TOP OF ENGINE)
VACUUM MOTOR
VEHICLE SPEED BRAKE NC SW RES/ACC SW IN
VEHICLE SPEED SENSOR (ON TOP RIGHT SIDE OF TRANSAXLE)
YEL WIRE
YEL/GRN WIRE
Go to component -> Cruise control circuit, with m/t -> THROTTLE POS GROUND-C IGNITION SWITCH
