Infiniti G20 II (1999-2002) seat cushion thermostat Wiring diagram
This page shows the only wiring diagram for the component.seat cushion thermostat, which is found in the car Infiniti G20 II (1999-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat cushion thermostat (1 of 1)
BLK WIRE
BRN/WHT WIRE
DRIVER'S HEATED SEAT SWITCH
DRIVER'S SEAT- BACK HEATER
FUSE 28
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
GRN/ORG WIRE
GRN/RED WIRE
HOT IN ON OR START
INDICATOR
LT BLU WIRE
NCA WIRE
ORG/BLK WIRE
PASSENGER'S HEATED SEAT SWITCH
PASSENGER'S SEAT BACK HEATER
PNK WIRE
RED WIRE
SEAT BACK HEATER
SEAT CUSHION HEATER
SEAT CUSHION THERMOSTAT
WHT WIRE
YEL WIRE
Go to component -> Heated seats circuit -> SEAT CUSHION THERMOSTAT
