Infiniti G20 II (1999-2002) ppl rr ss fr ss gnd fr ss fl ss gnd fl ss rl ss gnd rl ss sila txd diag l Wiring diagram
This page shows the only wiring diagram for the component.ppl rr ss fr ss gnd fr ss fl ss gnd fl ss rl ss gnd rl ss sila txd diag l, which is found in the car Infiniti G20 II (1999-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl rr ss fr ss gnd fr ss fl ss gnd fl ss rl ss gnd rl ss sila txd diag l (1 of 1)
4 8 5 DATA LINK CONNECTOR (UNDER LEFT DASH PANEL, NEAR FUSE BOX COVER)
ABS ACTUATOR, ELECTRIC UNIT (RIGHT FRONT CORNER OF ENGINE COMPARTMENT)
ABS IND.
BLK WIRE
BLK/RED WIRE
BLS IGN GND MOTOR RLY BATT GND
BLU WIRE
BLU/RED WIRE
BRN WIRE
COMBINATION METER
FUSE 11
FUSE 14
FUSE 3
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
FUSE F
FUSE H
FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT, NEXT TO BATTERY)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT FRONT WHEEL SENSOR
LEFT REAR WHEEL SENSOR
LT GRN WIRE
ORG/BLK WIRE
PNK WIRE
PPL
PPL RR SS FR SS GND FR SS FL SS GND FL SS RL SS GND RL SS SILA TXD DIAG L
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT WHEEL SENSOR
RIGHT REAR WHEEL SENSOR
RXD
STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brake circuits -> PPL RR SS FR SS GND FR SS FL SS GND FL SS RL SS GND RL SS SILA TXD DIAG L
