Infiniti G20 II (1999-2002) intake code 3 intake code 1 Wiring diagram
This page shows the only wiring diagram for the component.intake code 3 intake code 1, which is found in the car Infiniti G20 II (1999-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intake code 3 intake code 1 (1 of 1)
A/C AUTO AMP
AIR MIX DOOR MOTOR (BEHIND CENTER OF DASH, ON BOTTOM OF HEATER UNIT)
AMB SENS (+)
BLK WIRE
BLOWER MOTOR (BELOW RIGHT SIDE OF DASH)
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
COMP ON
FAN CONTROL AMPLIFIER (BEHIND RIGHT SIDE OF DASH, LEFT OF BLOWER MOTOR)
FAN FB
FAN GATE
FRE REC
FUSE 5
GRD
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START FUSE 1 FUSE 2
HOT IN ON OR START FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) FUSE 8
IGN
IGN 2
ILL
INCAR SENS (+)
INTAKE CODE 2
INTAKE CODE 3 INTAKE CODE 1
INTAKE DOOR MOTOR (BEHIND RIGHT SIDE OF DASH, ON LEFT SIDE OF AIR INTAKE UNIT)
INTAKE SENS
LAN SIG
LEFT FRONT FENDER)
LIGHT
LT GRN/RED WIRE
LT GRN/WHT WIRE
MODE DOOR MOTOR (LEFT END OF HEATER UNIT)
PNK WIRE
PNK/BLU WIRE
POSITION SWITCH)
PPL
RED/YEL WIRE
SENS GRD
SUN SENS
THERMAL TRANSMITTER (ON LOWER FRONT OF INTAKE MANIFOLD)
THERMO CONTROL AMPLIFIER (BEHIND RIGHT SIDE OF DASH)
VACTR (+)
W/T SENS
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/PPL WIRE
YEL/RED WIRE
Go to component -> Automatic a/c circuit (1 of 2) -> INTAKE CODE 3 INTAKE CODE 1
