Infiniti G20 II (1999-2002) ign ill ill ground Wiring diagram
This page shows the only wiring diagram for the component.ign ill ill ground, which is found in the car Infiniti G20 II (1999-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ign ill ill ground (1 of 1)
A/C SWITCH THERMO AMP INTAKE CODE (REC)
AIR MIX DOOR MOTOR (BEHIND CENTER OF DASH, ON BOTTOM OF HEATER UNIT)
AIR MIX MTR (HOT) PBR AIR MIX MTR (COLD) PTC PTC LED+ PTC LED-
B/L VENT
B/L VENT 8 9 1
BLK WIRE
BLOWER MOTOR
BLU BLU WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
DEF D/F
FAN RESISTOR (BEHIND RIGHT SIDE OF DASH, NEAR BLOWER MOTOR)
FAN SWITCH
FOOT
FRE
FRE REC
FUSE 1 FUSE 1
FUSE 2
FUSE 6
FUSE 8
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
GRY WIRE
HOT IN ON
HOT IN ON OR START
IGN ILL ILL GROUND
INTAKE CODE (FRE)
INTAKE DOOR MOTOR (BEHIND RIGHT SIDE OF DASH, ON LEFT SIDE OF AIR INTAKE UNIT)
LT GRN WIRE
LT GRN/RED WIRE
MODE ACTR (VENT) MODE ACTR (DEF)
OFF
PPL
PPL 2 4
PTC (INTEGRAL TO A/C PUSH CONTROL UNIT)
PUSH CONTROL UNIT
REC
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
THERMO CONTROL AMPLIFIER (RIGHT SIDE OF DASH)
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Manual a/c circuit (1 of 2) -> IGN ILL ILL GROUND
