Infiniti G20 II (1999-2002) cellular phone antenna Wiring diagram
This page shows the only wiring diagram for the component.cellular phone antenna, which is found in the car Infiniti G20 II (1999-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cellular phone antenna (1 of 1)
+9.5 H/S GND T DATA C DATA VOICE GND R DATA RX VOICE TX VOICE
11 10 12 13 TEL SIG + TEL SIG - TEL ON SIG GND
4 5 RX TX
AIR BAG
AIR BAG DIAGNOSIS SENSOR UNIT (BELOW REAR OF CENTER CONSOLE)
AUDIO
BLK WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
CELLULAR PHONE ANTENNA
DATA LINK CONNECTOR (DLC) (UNDER LEFT DASH PANEL, NEAR FUSE BOX COVER)
DATA/OUT
FUSE 36
FUSE 5
FUSE 8
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN)
FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT, NEXT TO BATTERY)
GPS ANTENNA
GPS ANTENNA CELL ANTENNA
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/BLU WIRE
HANDSET (TO ADAPTER HARNESS)
HORN RELAY (IN RELAY BOX)
HORN SYSTEM
HORN/RY
HOT AT ALL TIMES
HOT IN ON OR START
INFORMATION
IVCS
IVCS OUTPUT
IVCS SWITCH
IVCS UNIT (UNDER RIGHT SIDE OF REAR PACKAGE SHELF)
IVCS UNLOCK
LT GRN WIRE
MAYDAY
MICROPHONE
NCA WIRE
NO SERVICE
OUTSIDE DOOR HANDLE SWITCH (LEFT FRONT DOOR KEY CYLINDER SWITCH)
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
PPL
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
REDIAL
SMART ENTRANCE CONTROL UNIT (BEHIND DASH, LEFT OF STEERING COLUMN)
SPIRAL CABLE
STEERING WHEEL SWITCH (TEL)
TX RX
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Navigation circuit -> CELLULAR PHONE ANTENNA
