Infiniti G20 II (1999-2002) 2 33 39 def out ignition def sw Wiring diagram
This page shows the only wiring diagram for the component.2 33 39 def out ignition def sw, which is found in the car Infiniti G20 II (1999-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 2 33 39 def out ignition def sw (1 of 1)
2 33 39 DEF OUT IGNITION DEF SW
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
CONDENSER
DOOR MIRROR DEFOGGER RELAY (BEHIND LEFT KICK PANEL)
FUSE 39
FUSE BLOCK (BEHIND DASH, LEFT OF STEERING COLUMN) FUSE 8
FUSE BLOCK FUSE 9 (BEHIND DASH, LEFT OF STEERING COLUMN)
FUSE, FUSIBLE LINK BOX (LEFT FRONT OF ENGINE COMPT, NEXT TO BATTERY) FUSE 40
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
ILLUM REAR WINDOW DEFOGGER SWITCH
LEFT DOOR MIRROR DEFOGGER
NCA WIRE
ON IND.
PPL/WHT WIRE
REAR WINDOW DEFOGGER RELAY (BEHIND LEFT KICK PANEL)
RED WIRE
RED/YEL WIRE
RIGHT DOOR MIRROR DEFOGGER REAR WINDOW DEFOGGER
Go to component -> Defogger circuit -> 2 33 39 DEF OUT IGNITION DEF SW
