Infiniti G20 II (1999-2002) 15 16 air bag ind seat belt Wiring diagram
This page shows the only wiring diagram for the component.15 16 air bag ind seat belt, which is found in the car Infiniti G20 II (1999-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 15 16 air bag ind seat belt (1 of 1)
15 16 AIR BAG IND SEAT BELT
22 18 15 VSP INPUT SET LAMP OUT CRUISE LAMP
ABS ACTUATOR,ELECTRIC UNIT (CONTROL UNIT) (RT FRONT CORNER OF ENGINE COMPT)
ABS FAIL IND
AIR BAG DIAGNOSIS SENSOR UNIT (BELOW REAR OF CENTER CONSOLE)
BLK WIRE
BLK/ YEL WIRE
BLU WIRE
BLU/RED WIRE
BRAKE FLUID LEVEL SWITCH (IN BRAKE FLUID RESERVOIR)
BRN/WHT WIRE
COMBINATION METER
DIODE
ECM (ECCS) CONTROL MODULE (BEHIND CENTER OF DASH)
FROM COMBINATION METER (DIAGRAM 1 OF 2)
GRN/WHT WIRE
HI-BEAM IND
ILLUMINATION
LEFT TURN IND
LT BLU WIRE
LT GRN (OR YEL/BLK) WIRE
LT GRN WIRE
MAL IND DRIVER
OD OFF
ODO/TRIP ILLUMINATION
OIL PRESSURE SWITCH (ON RIGHT FRONT SIDE OF CYLINDER BLOCK)
ORG/ WIRE
ORG/BLU WIRE
OTHERS
PARKING BRAKE SWITCH
RIGHT TURN IND
TACH OUT
TRANSMISSION CONTROL MODULE (BEHIND LOWER CENTER OF DASH)
VOLTAGE REGULATOR
WASHER LEVEL SWITCH (FLUID RESERVOIR)
WHT/BLK WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/PPL WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> 15 16 AIR BAG IND SEAT BELT
