Infiniti G20 I (1991-1996) resistor, condenser power window relay Wiring diagram
This page shows the only wiring diagram for the component.resistor, condenser power window relay, which is found in the car Infiniti G20 I (1991-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram resistor, condenser power window relay (1 of 1)
A/T
ANTI-LOCK CONTROL UNIT
ASCD SWITCH ASCD HOLD RELAY
BACK-UP LAMP SWITCH (M/T) INHIBITOR SWITCH (A/T)
BLK WIRE
BLK/RED WIRE
BLOWER RELAY
BRN WIRE
CANADA
COMBINATION METER HEATED MIRROR RELAY
DATA LINK CONNECTOR (A/T)
DAYTIME LIGHT CONTROL UNIT
DAYTIME LIGHT RELAY
FROM ACCESSORY RELAY-1
FROM IGNITION SWITCH
FRONT FOG LAMP RELAY
FUEL PUMP RELAY
FUSE BLOCK
FUSE G
FUSE H
FUSE M
FUSE O
FUSE U FUSE V
FUSE Z
GRN/WHT WIRE
HAZARD SWITCH
IGNITION COIL
IGNITION RELAY 1
J/C 4
M/T
PAIRC- SOLENOID VALVE
PNK WIRE
POWER ANTENNA TIMER REAR WINDOW DEFOGGER RELAY
RADIATOR FAN RELAY 2
RADIATOR FAN RELAY-1
RADIATOR FAN RELAY-3 (A/T)
RED/BLU WIRE
RESISTOR, CONDENSER POWER WINDOW RELAY
SHIFTLOCK CONTROL UNIT
SMJ
SRS CONTROL UNIT
THEFT WARNING RELAY-2
THROTTLE POSITION SWITCH
TIME CONTROL UNIT
WHT/GRN WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> RESISTOR, CONDENSER POWER WINDOW RELAY
