Infiniti G20 I (1991-1996) multi-remote control Wiring diagram
This page shows the only wiring diagram for the component.multi-remote control, which is found in the car Infiniti G20 I (1991-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram multi-remote control (1 of 1)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CIRCUIT BREAKER-1 (LEFT DASH)
DIODE (RIGHT DASH)
DOOR LOCK TIMER (RIGHT KICK PANEL)
DOOR WARNING LIGHT
FEEDER CABLE
FUSE
FUSE (LEFT DASH)
FUSE BLOCK
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INTERIOR LIGHT)
KEY SWITCH
LOCK UNLOCK SWITCH
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
MULTI-REMOTE CONTROL
MULTI-REMOTE CONTROL UNIT (RIGHT REAR OF TRUNK)
OFF ON DOOR
ORG/ WIRE
ORG/BLK WIRE
ORG/BLU WIRE
PNK RELAYS 1, 2 (EXTERIOR LIGHTS SYSTEM) WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SWITCH (CENTER OF DASH)
THEFT WARNING CONTROL
THEFT WARNING CONTROL UNIT
TIME CONTROL UNIT
TIME CONTROL UNIT (OPTIONAL) (BEHIND LEFT SIDE OF DASH)
TRUNK LID OPENER ACTUATOR (CENTER REAR OF TRUNK)
TRUNK LID OPENER CANCEL
TRUNK ROOM LAMP
TRUNK ROOM LAMP SWITCH (CENTER REAR OF TRUNK LID)
TRUNK/FUEL LID OPENER SWITCH
UN- LOCK LOCK
UNIT)
WHT WIRE
WHT/BLK WIRE
WINDOW ANTENNA
YEL WIRE
YEL/RED WIRE
