Infiniti G20 I (1991-1996) left rear door unlock sensor Wiring diagrams
This page contains all the electrical diagrams for the component. left rear door unlock sensor, in which he is found in the car Infiniti G20 I (1991-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left rear door unlock sensor (1 of 2)
1994 VFTC
BETWEEN FULL STROKE, NORMAL KEY CYLINDER WITHDRAWN
BLK WIRE
BLU WIRE
DIODE
DIODES (BEHIND CENTER CONSOLE)
DOOR LOCK TIMER
DOOR WARNING LIGHT
FUSE
FUSE BLOCK (LEFT I/P)
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOOD SWITCH (RIGHT FRONT SHOCK TOWER)
HOT AT ALL TIMES
HOT IN
HOT IN ACC OR RUN
HOT IN RUN OR START
INTERIOR LIGHT)
J/C-4 (LEFT FRONT ENGINE COMPT)
LAMP
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR UNLOCK SENSOR
LEFT REAR RIGHT REAR DOOR SWITCH DOOR SWITCH
LOCK
LOCK DRIVER'S DOOR UNLOCK SENSOR
LOCK PASSENGER'S DOOR UNLOCK SENSOR
LT GRN WIRE
LT GRN/RED WIRE
MULTI- REMOTE CONTROL UNIT
ORG/ WIRE
PPL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR UNLOCK SENSOR
SECURITY LAMP
THEFT WARNING CONTROL UNIT
TRUNK LID UNLOCK KEY SWITCH, KEY CYLINDER TAMPER SWITCH
TRUNK ROOM
TRUNK ROOM LAMP SWITCH
UNLOCK
W/ MULTI-REMOTE CONTROL SYSTEM
W/O MULTI- REMOTE CONTROL SYSTEM
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Anti-theft circuit (1 of 2) -> LEFT REAR DOOR UNLOCK SENSOR
Wiring diagram left rear door unlock sensor (2 of 2)
A/T MODE SWITCH
AUTOMATIC SEAT BELT CONTROL UNIT
BLK WIRE
BLU WIRE
DETENTION SWITCH
ELR CONTROL UNIT
FUEL FILLER LID OPENER ACTUATOR
FUEL PUMP
FUEL TANK GAUGE UNIT
HIGH MOUNTED STOP LAMP
LEFT FRONT DOOR SWITCH
LEFT FRONT POWER SEAT SWITCH
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP (STOP AND TAIL)
LEFT REAR COMBINATION LAMP BACK- UP
LEFT REAR DOOR UNLOCK SENSOR
LEFT REAR SIDE MARKER LAMP
LEFT SHOULDER BELT BUCKLE SWITCH
LEFT SHOULDER BELT LOCKING CANCELER
LOCK AND UNLOCK SWITCH
MULTI- REMOTE CONTROL UNIT
OVERDRIVE CANCEL SWITCH
OVERDRIVE CONTROL SWITCH
OVERDRIVE SWITCH
POWER ANTENNA TIMER
POWER WINDOW MAIN SWITCH
RIGHT FRONT DOOR SWITCH
RIGHT FRONT POWER SEAT SWITCH
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP (STOP AND TAIL)
RIGHT REAR COMBINATION LAMP BACK- UP
RIGHT REAR DOOR UNLOCK SENSOR
RIGHT REAR LIMIT SWITCH
RIGHT REAR SIDE MARKER LAMP
RIGHT SHOULDER BELT BUCKLE SWITCH
RIGHT SHOULDER BELT LOCKING CANCELER
SEAT BELT BUCKLE SWITCH
SHIFT LOCK SOLENOID
TRUNK LID OPENER ACTUATOR
TRUNK LID UNLOCK KEY SWITCH AND KEY CYLINDER TAMPER SWITCH
TRUNK ROOM LAMP SWITCH
Go to component -> Ground distribution circuit (4 of 4) -> LEFT REAR DOOR UNLOCK SENSOR
