Infiniti G20 I (1991-1996) left rear combination lamp back- up Wiring diagram
This page shows the only wiring diagram for the component.left rear combination lamp back- up, which is found in the car Infiniti G20 I (1991-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear combination lamp back- up (1 of 1)
A/T MODE SWITCH
AUTOMATIC SEAT BELT CONTROL UNIT
BLK WIRE
BLU WIRE
DETENTION SWITCH
ELR CONTROL UNIT
FUEL FILLER LID OPENER ACTUATOR
FUEL PUMP
FUEL TANK GAUGE UNIT
HIGH MOUNTED STOP LAMP
LEFT FRONT DOOR SWITCH
LEFT FRONT POWER SEAT SWITCH
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP (STOP AND TAIL)
LEFT REAR COMBINATION LAMP BACK- UP
LEFT REAR DOOR UNLOCK SENSOR
LEFT REAR SIDE MARKER LAMP
LEFT SHOULDER BELT BUCKLE SWITCH
LEFT SHOULDER BELT LOCKING CANCELER
LOCK AND UNLOCK SWITCH
MULTI- REMOTE CONTROL UNIT
OVERDRIVE CANCEL SWITCH
OVERDRIVE CONTROL SWITCH
OVERDRIVE SWITCH
POWER ANTENNA TIMER
POWER WINDOW MAIN SWITCH
RIGHT FRONT DOOR SWITCH
RIGHT FRONT POWER SEAT SWITCH
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP (STOP AND TAIL)
RIGHT REAR COMBINATION LAMP BACK- UP
RIGHT REAR DOOR UNLOCK SENSOR
RIGHT REAR LIMIT SWITCH
RIGHT REAR SIDE MARKER LAMP
RIGHT SHOULDER BELT BUCKLE SWITCH
RIGHT SHOULDER BELT LOCKING CANCELER
SEAT BELT BUCKLE SWITCH
SHIFT LOCK SOLENOID
TRUNK LID OPENER ACTUATOR
TRUNK LID UNLOCK KEY SWITCH AND KEY CYLINDER TAMPER SWITCH
TRUNK ROOM LAMP SWITCH
Go to component -> Ground distribution circuit (4 of 4) -> LEFT REAR COMBINATION LAMP BACK- UP
