Infiniti G20 I (1991-1996) left door latch switch Wiring diagram
This page shows the only wiring diagram for the component.left door latch switch, which is found in the car Infiniti G20 I (1991-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left door latch switch (1 of 1)
A/T CONTROL UNIT
ACCESSORY
ACCESSORY RELAY 1
ASCD CONTROL UNIT
ASCD SWITCH
ASHTRAY ILLUMINATION
BLK WIRE
BLOWER RELAY
BULB CHECK RELAY
CIGARETTE LIGHTER
CLUTCH INTERLOCK SWITCH
COMBINATION FLASHER UNIT
DAYTIME LIGHT CONTROL UNIT
DOOR LOCK TIMER
DOOR MIRROR SWITCH
FRONT FOG LAMP SWITCH
FUSE BLOCK
GLOVE BOX LAMP/ SWITCH
IGNITION RELAY-1 RELAY-1
INSTRUMENT CLUSTER
LEFT DOOR LATCH SWITCH
LEFT DOOR MIRROR HEATER
LEFT FRONT DOOR LOCK ACTUATOR
LEFT FRONT DOOR LOCK KEY SWITCH
LEFT FRONT LIMIT SWITCH
LEFT FRONT POWER WINDOW SWITCH
LEFT LOCK KNOB SWITCH
M/T MODELS
MODE DOOR MOTOR
POWER WINDOW AMPLIFIER
POWER WINDOW RELAY
PUSH CONTROL UNIT
REAR WINDOW DEFOGGER SWITCH
RIGHT DOOR LATCH SWITCH
RIGHT DOOR MIRROR HEATER
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT FRONT DOOR LOCK KEY SWITCH
RIGHT FRONT LIMIT SWITCH
RIGHT LOCK KNOB SWITCH
SHIFT LOCK CONTROL UNIT
SRS CONTROL UNIT
THEFT WARNING CONTROL UNIT
TIME CONTROL UNIT
VENT MODE SWITCH
WIPER MOTOR
Go to component -> Ground distribution circuit (3 of 4) -> LEFT DOOR LATCH SWITCH
