Infiniti G20 I (1991-1996) intake door motor a/c relay Wiring diagram
This page shows the only wiring diagram for the component.intake door motor a/c relay, which is found in the car Infiniti G20 I (1991-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intake door motor a/c relay (1 of 1)
ACCESSORY RELAY 1
ACCESSORY RELAY 2
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR
BLU WIRE
BLU/RED WIRE
BRN WIRE
CANADA
CIGARETTE LIGHTER
CLUTCH INTERLOCK RELAY (U.S.A.) (M/T)
DAYTIME LAMPS RELAY
DIODE DIODE
DOOR MIRROR SWITCH
FROM FUSE Y
FROM FUSIBLE LINK A
FROM FUSIBLE LINK D
FUSE BLOCK
FUSE D FUSE E
FUSE F
FUSE I FUSE J
FUSE K
FUSE L
FUSE P
FUSES G,H,&O
GRN/WHT WIRE
GRN/YEL WIRE
IGNITION SWITCH
INTAKE DOOR MOTOR A/C RELAY
J/C 4
LT GRN WIRE
OFF
ORG/BLK WIRE
PPL
PPL/WHT WIRE
RADIO
THEFT WARNING RELAY-2
THEFT WARNING RELAY-2 (U.S.A.) (M/T)
THEFT WARNING UNIT
THERMO CONTROL AMP
TIME CONTROL UNIT PUSH CONTROL UNIT
TO IGNITION RELAY-1
WASHER MOTOR
WHT WIRE
WHT/BLU WIRE
WIPER MOTOR
WIPER RELAY
