Infiniti G20 I (1991-1996) front door switch seat belt relay, warning chime interior lamp Wiring diagram
This page shows the only wiring diagram for the component.front door switch seat belt relay, warning chime interior lamp, which is found in the car Infiniti G20 I (1991-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front door switch seat belt relay, warning chime interior lamp (1 of 1)
1995 VFTC
4 5 PNK WIRE
BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
FRONT DOOR SWITCH SEAT BELT RELAY, WARNING CHIME INTERIOR LAMP
FUSE
FUSE BLOCK FUSE (LEFT I/P)
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
KEY SWITCH
LT GRN/BLK WIRE
PNK 14 15 PPL WIRE
PNK WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
SEAT BELT RELAY
TIME CONTROL UNIT (BEHIND LEFT SIDE OF I/P)
WHT WIRE
WIPER RELAY
WIPER SWITCH WASHER MOTOR, WIPER SWITCH WIPER SWITCH PNK PPL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Time control unit circuit -> FRONT DOOR SWITCH SEAT BELT RELAY, WARNING CHIME INTERIOR LAMP
