Infiniti G20 I (1991-1996) eccs relay Wiring diagram
This page shows the only wiring diagram for the component.eccs relay, which is found in the car Infiniti G20 I (1991-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram eccs relay (1 of 1)
ALTERNATOR
ANTI-LOCK ACTUATOR RELAY
ANTI-LOCK MOTOR RELAY
BATTERY
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
CIRCUIT BREAKER 1
DAYTIME LIGHT CONTROL UNIT
DOOR LOCK TIMER
ECCS RELAY
FRONT AMPLIFIER
FUSE
FUSE 1
FUSE 2
FUSE 3
FUSE BLOCK
FUSE FUSE
FUSE, FUSIBLE LINK BOX
FUSE, FUSIBLE LINK BOX FUSE 4
FUSIBLE LINK A
FUSIBLE LINK B
FUSIBLE LINK C
FUSIBLE LINK D
FUSIBLE LINK E
FUSIBLE LINK F
FUSIBLE LINK G
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRY WIRE
HAZARD SWITCH MULTI- REMOTE CONTROL RELAY
HORN RELAY-1 LIGHTING SWITCH
IACV-AAC VALVE STOPLAMP SWITCH
INJECTOR NO.1
INJECTOR NO.2 INJECTOR NO.3
INJECTOR NO.4
J/C 3
LEFT POWER SEAT SWITCH RIGHT POWER SEAT SWITCH
LIGHTING SWITCH
MULTI- REMOTE CONTROL UNIT
NCA WIRE
ORG/BLU WIRE
POWER ANTENNA TIMER RADIO
POWER WINDOW RELAY
RADIATOR FAN RELAY 2
RADIATOR FAN RELAY-1
RADIATOR FAN RELAY-1 (A/T)
RADIATOR FAN RELAY-3 (A/T)
REAR AMPLIFIER
REAR WINDOW DEFOGGER RELAY
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SMJ
TIME CONTROL UNIT KEY SWITCH
TO ACCESSORY RELAY-2
TO IGNITION RELAY-1, ACCESSORY RELAY-1
TO IGNITION SWITCH
TRUNK LAMP SPOT LAMP INTERIOR LAMP
TRUNK LID, FUEL FILLER LID OPENER SWITCH
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
Go to component -> Power distribution circuit (1 of 3) -> ECCS RELAY
