Infiniti G20 I (1991-1996) clutch interlock relay Wiring diagram
This page shows the only wiring diagram for the component.clutch interlock relay, which is found in the car Infiniti G20 I (1991-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram clutch interlock relay (1 of 1)
A/T
A/T M/T CANADA
A/T M/T USA CANADA (ON TRANSMISSION)
ASCD STEERING SWITCH
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
CLUTCH INTERLOCK RELAY
CLUTCH INTERLOCK SWITCH (ON CLUTCH PEDAL MOUNTING BRACKET)
CRUISE CONTROL SYSTEM
DAYTIME LIGHT CONTROL UNIT
DRL
FUSE
FUSE, FUSIBLE LINK BOX (LEFT FRONT ENGINE COMPT)
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRY WIRE
HIGH PITCH HORN
HORN RELAY 1
HORN RELAY 2
HORN SWITCH
HOT AT ALL TIMES
IGNITION SWITCH
INHIBITOR RELAY (A/T)
INHIBITOR SWITCH
J/C 3 (LEFT FRONT FENDER)
LEFT HEADLAMP LO LO HI HI
LOW PITCH HORN
LT GRN WIRE
M/T
M/T USA
M/T USA CANADA
NCA WIRE
OFF
ORG/ WIRE
PPL
RED WIRE
RELAY BOX-1 (RIGHT SIDE ENGINE COMPT)
RELAY BOX-2 (LEFT FRONT ENGINE COMPT) M/T
RIGHT HEADLAMP
RUN WIRE
SPIRAL CABLE
STARTER MOTOR
THEFT WARNING HORN
THEFT WARNING RELAY-1
THEFT WARNING RELAY-2
W/ DRL
W/O
W/O DRL W/DRL
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Anti-theft circuit (2 of 2) -> CLUTCH INTERLOCK RELAY
