Infiniti G20 I (1991-1996) a/t mode switch Wiring diagrams
This page contains all the electrical diagrams for the component. a/t mode switch, in which he is found in the car Infiniti G20 I (1991-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/t mode switch (1 of 2)
A/T MODE SWITCH
AUTOMATIC SEAT BELT CONTROL UNIT
BLK WIRE
BLU WIRE
DETENTION SWITCH
ELR CONTROL UNIT
FUEL FILLER LID OPENER ACTUATOR
FUEL PUMP
FUEL TANK GAUGE UNIT
HIGH MOUNTED STOP LAMP
LEFT FRONT DOOR SWITCH
LEFT FRONT POWER SEAT SWITCH
LEFT LICENSE LAMP
LEFT REAR COMBINATION LAMP (STOP AND TAIL)
LEFT REAR COMBINATION LAMP BACK- UP
LEFT REAR DOOR UNLOCK SENSOR
LEFT REAR SIDE MARKER LAMP
LEFT SHOULDER BELT BUCKLE SWITCH
LEFT SHOULDER BELT LOCKING CANCELER
LOCK AND UNLOCK SWITCH
MULTI- REMOTE CONTROL UNIT
OVERDRIVE CANCEL SWITCH
OVERDRIVE CONTROL SWITCH
OVERDRIVE SWITCH
POWER ANTENNA TIMER
POWER WINDOW MAIN SWITCH
RIGHT FRONT DOOR SWITCH
RIGHT FRONT POWER SEAT SWITCH
RIGHT LICENSE LAMP
RIGHT REAR COMBINATION LAMP (STOP AND TAIL)
RIGHT REAR COMBINATION LAMP BACK- UP
RIGHT REAR DOOR UNLOCK SENSOR
RIGHT REAR LIMIT SWITCH
RIGHT REAR SIDE MARKER LAMP
RIGHT SHOULDER BELT BUCKLE SWITCH
RIGHT SHOULDER BELT LOCKING CANCELER
SEAT BELT BUCKLE SWITCH
SHIFT LOCK SOLENOID
TRUNK LID OPENER ACTUATOR
TRUNK LID UNLOCK KEY SWITCH AND KEY CYLINDER TAMPER SWITCH
TRUNK ROOM LAMP SWITCH
Go to component -> Ground distribution circuit (4 of 4) -> A/T MODE SWITCH
Wiring diagram a/t mode switch (2 of 2)
A/T CONTROL UNIT (LEFT KICK PANEL)
A/T FLUID TEMP SENSOR
A/T MODE SWITCH
ASCD CONTROL UNIT (BEHIND LEFT I/P)
AUTOMATIC TRANSAXLE
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CLOSED THROTTLE
CLUTCH SOL
CMFRT PWR
CRUISE CONTROL
DATA LINK CONNECTOR (FOR CONSULT) (BELOW LEFT SIDE OF I/P)
DIODES (1994, 95) (LEFT I/P)
DROPPING RESISTOR (LEFT SIDE OF ENGINE COMPT)
ECCS CONTROL MODULE
ENGINE COOLANT TEMPERATURE SENSOR (LEFT REAR OF ENGINE)
EXTERIOR LIGHTS (BACKUP)
FUSE
FUSE BLOCK (LEFT KICK PANEL)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER (TACHOMETER)
LINE PRESS SOL VALVE
LT GRN WIRE
LT GRN/BLK WIRE
LT LT PNK WIRE
NCA WIRE
O/D CONTROL SWITCH
O/D OFF IND
ORG/ WIRE
ORG/BLU WIRE
OVER- SHIFT SOL VALVE SHIFT SOL VALVE TCC SOL VALVE
PNK WIRE
PNK/BLU WIRE
POWER
PPL
RED WIRE
RED/YEL WIRE
REVOLUTION SENSOR
RUN WIRE
SPEEDOMETER
THROTTLE POSITION SENSOR (ON THROTTLE BODY)
THROTTLE POSITION SWITCH (ON THROTTLE BODY)
VEHICLE SPEED SENSOR
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WOT
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Transmission circuit -> A/T MODE SWITCH
