Infiniti G20 I (1991-1996) ascd hold relay wiring diagram
This page shows the only wiring diagram for the component.ascd hold relay, which is found in the car Infiniti G20 I (1991-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
ascd hold relay wiring diagram (1 of 1)
A/T MODELS
ACTUATOR RELAY
ASCD HOLD RELAY
BLK WIRE
BRAKE FLUID LEVEL SWITCH
IACV-AIR REGULATOR
IACV-FICD SOLENOID VALVE
INHIBITOR SWITCH
LEFT CLEARANCE LAMP
LEFT FRONT FENDER)
LEFT FRONT FOG LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT HEADLAMP
LEFT TURN SIGNAL LAMP
M/T MODELS
NEUTRAL POSITION SWITCH
RADIATOR FAN MOTOR 1
RADIATOR FAN MOTOR 2
RADIATOR FAN RELAY 2
RADIATOR FAN RELAY 3
RELAY BOX
RIGHT CLEARANCE LAMP
RIGHT FRONT FOG LAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT HEADLAMP
RIGHT TURN SIGNAL LAMP
TRIPLE PRESSURE SWITCH
WASHER LEVEL SWITCH
WIPER SWITCH
Go to component -> Ground distribution circuit (2 of 4) -> ASCD HOLD RELAY
