Infiniti FX50 II facelift (2011-2013) mirror change over switch switch door mirror remote control switch Wiring diagram
This page shows the only wiring diagram for the component.mirror change over switch switch door mirror remote control switch, which is found in the car Infiniti FX50 II facelift (2011-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror change over switch switch door mirror remote control switch (1 of 1)
A/T SHIFT SELECTOR (DETENTION SWITCH)
BACK- WARD
BACKWARD
BLK WIRE
BLU WIRE
BRN WIRE
CHANGE OVER SWITCH DOOR MIRROR REMOTE CONTROL SWITCH
CIRCUIT BREAKER
CUSHION SIDE DEFLATE SOLENOID
CUSHION SIDE INFLATE SOLENOID
DEFLATE CUSHION SIDE
DEFLATE CUSHION SIDE INFLATE
DEFLATE SEAT BACK SIDE
DN LEFT
DRIVER SIDE FRONT SEAT
FOR- WARD
FORWARD/
GRN WIRE
GRY WIRE
IND 1
IND 2
IND 2 MEMORY
INFLATE
LT BLU WIRE
LT GRN WIRE
LUMBAR SUPPORT
MEMORY
MEMORY 1 SWITCH
MEMORY 2 SET SWITCH SWITCH
MEMORY 2 SWITCH
MEMORY IND 1
MIRROR CHANGE OVER SWITCH SWITCH DOOR MIRROR REMOTE CONTROL SWITCH
MIRROR SWITCH
MOTOR
OFF
OFF OFF
OFF OFF OFF
ON ON ON
OPEN/CLOSE SWITCH
ORG/ WIRE
PNK WIRE
PPL
PPL PNK WIRE
PUMP
PUMP RELAY
RED WIRE
RIGHT
SEAT BACK SIDE DEFLATE SOLENOID
SEAT BACK SIDE INFLATE SOLENOID
SEAT MEMORY SWITCH
SET SWITCH
SIDE SUPPORT SWITCH
SIDE SUPPORT SWITCH INFLATE
SIDE SUPPORT UNIT
SWITCH
SWITCH FORWARD
TAN WIRE
UP DN LEFT
WHT WIRE
YEL WIRE
Go to component -> Memory systems circuit (2 of 3) -> MIRROR CHANGE OVER SWITCH SWITCH DOOR MIRROR REMOTE CONTROL SWITCH
