Infiniti FX50 II facelift (2011-2013) its comm-h ppl release sw Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 BATT BATT 1 2 3 4 5 6 IGN COMM-H CAN-H GND COMM-L CAN-L A/T ASSEMBLY (ON TRANSMISSION) BLK WIRE BLU WIRE BOOSTER SOLENOID BOOSTER SOLENOID RELEASE SWITCH BRAKE BOOSTER BRAKE BOOSTER (LEFT REAR CORNER OF ENGINE COMPT) BRAKE BOOSTER CONTROL UNIT BRAKE BOOSTER CONTROL UNIT (RIGHT SIDE OF LUGGAGE COMPT) BRAKE PRESSURE SENSOR BRN WIRE CAN-H CAN-H- CAN-L- CHIME SIG COMM (H) COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM ITS COMM-H RELEASE SW PPL COMPUTER DATA LINES SYSTEM PNK WIRE DRIVE SIG FUSE FUSE 33 FUSE 45 FUSE 50 FUSE, FUSIBLE LINK BLOCK GND DRIVE SIG GND GND CHIME SIG RELEASE SW GND PNK COMM-L PNK CAN-L WIRE GND VOUT VCC GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE, FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPT) HOT IN ON OR START IBA OFF SW IBA OFF SWITCH ICC BRAKE HOLD RELAY (IN FUSE, FUSIBLE LINK BLOCK) ICC BRAKE SWITCH ICC BRAKE SWITCH (ON BRAKE PEDAL BRACKET) ICC SENSOR INTEGRATED UNIT ICC WARNING CHIME ICC WARNING CHIME (LEFT END OF DASH) IGN INPUT SPEED SENSOR 1 IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) ITS COMM-H PPL RELEASE SW JOINT CONNECTOR LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE OUTPUT SPEED SENSOR PNK COMPUTER DATA LINES SYSTEM ITS COMM-L RELEASE SW WIRE PNK ITS COMM-L WIRE PNK PNK COMPUTER DATA LINES SYSTEM WIRE PNK WIRE PPL RED WIRE RELEASE SW RELEASE SWITCH SEN GND SEN PWR SEN SIG SOL GND SOL PWR TCM (TRANSMISSION CONTROL MODULE) TRANSMISSION RANGE SWITCH VCC VOUT WHT WIRE YEL WIRE
