Infiniti FX50 II facelift (2011-2013) engine engine controls, controls transmissions system systems Wiring diagram
This page shows the only wiring diagram for the component.engine engine controls, controls transmissions system systems, which is found in the car Infiniti FX50 II facelift (2011-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine engine controls, controls transmissions system systems (1 of 1)
A/C RELAY
BLK WIRE
BLU WIRE
BRN WIRE
COOLING FANS SYSTEM
CRUISE CONTROL, ANTI-LOCK BRAKES SYSTEMS
ECM RELAY
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
ENGINE COOLING CONTROLS FANS SYSTEM SYSTEM
ENGINE ENGINE CONTROLS, CONTROLS TRANSMISSIONS SYSTEM SYSTEMS
FROM FUSE 48 (DIAGRAM 3 OF 3)
FROM FUSE 58 (DIAGRAM 3 OF 3)
FROM FUSE, FUSIBLE LINK BLOCK FUSIBLE LINK H (DIAGRAM 1 OF 3)
FROM FUSIBLE LINK HOLDER FUSIBLE LINK D (DIAGRAM 1 OF 3)
FROM FUSIBLE LINK HOLDER FUSIBLE LINK F (DIAGRAM 1 OF 3)
FRONT FOG LAMP RELAY
FRONT WIPER HIGH RELAY
FRONT WIPER HIGH RELAY FRONT WIPER RELAY
FRONT WIPER RELAY
FUEL PUMP RELAY
FUSE 41
FUSE 42
FUSE 42 FUSE 43 FUSE 44
FUSE 43
FUSE 44
FUSE 45
FUSE 46
FUSE 46 FUSE 47
FUSE 47
FUSE 49
FUSE 50
FUSE 51
FUSE 52
FUSE 53
FUSE 58
FUSE 60
FUSE BLOCK (J/B)
FUSE BLOCK (J/B) (LEFT KICK PANEL)
GRN WIRE
HEAD LAMP (LOW) RELAY
HEAD LAMP HIGH RELAY
HEADLIGHTS SYSTEM
IGNITION RELAY
INTERIOR LIGHTS, BODY COMPUTER SYSTEMS
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
SOUND SYSTEM, SHIFT INTERLOCK, INTERIOR LIGHTS SYSTEMS
STARTER RELAY
TAIL LAMP RELAY
TAN WIRE
THROTTLE CONTROL MOTOR RELAY
TO FUSE 49 (DIAGRAM 3 OF 3)
TO FUSE 60 (DIAGRAM 3 OF 3)
WHT WIRE
WIPER/WASHER (RIGHT SIDE SYSTEM OF ENGINE COMPT)
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit (3 of 3) -> ENGINE ENGINE CONTROLS, CONTROLS TRANSMISSIONS SYSTEM SYSTEMS
