Infiniti FX50 II facelift (2011-2013) electronic passive power restraints steering system system Wiring diagram
This page shows the only wiring diagram for the component.electronic passive power restraints steering system system, which is found in the car Infiniti FX50 II facelift (2011-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electronic passive power restraints steering system system (1 of 1)
ACC IND
ACCESSORY RELAY 2
ACCESSORY RELAY 2 (RIGHT SIDE OF DASH)
ANTI-LOCK BRAKES SYSTEM
ANTI-THEFT SYSTEM
BATTERY
BCM (BODY CONTROL MODULE)
BCM (BODY CONTROL MODULE) (RIGHT END OF DASH)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BODY COMPUTER SYSTEM
BODY COMPUTER, MEMORY& SEATS SYSTEMS
BODY COMPUTER, SEATS, INTERIOR LIGHTS, MEMORY SYSTEMS
BRN WIRE
ELECTRONIC PASSIVE POWER RESTRAINTS STEERING SYSTEM SYSTEM
ELECTRONIC POWER STEERING SYSTEM
ENGINE CONTROLS SYSTEM
EXTERIOR LIGHTS, CRUISE CONTROL SYSTEMS
FROM FUSIBLE LINK HOLDER FUSIBLE LINK P (DIAGRAM 2 OF 3)
FUSE 10
FUSE 11
FUSE 31
FUSE 32
FUSE 33
FUSE 34
FUSE 36
FUSE 37
FUSE 38
FUSE 5
FUSE 5 FUSE 9
FUSE 6
FUSE 61
FUSE 62
FUSE 63
FUSE 63 FUSE 61 FUSE 62 FUSIBLE LINK Q
FUSE 7
FUSE 8
FUSE 9
FUSE, FUSIBLE LINK BLOCK
FUSE, FUSIBLE LINK BLOCK FUSIBLE LINK L FUSE (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK A
FUSIBLE LINK B
FUSIBLE LINK C
FUSIBLE LINK D
FUSIBLE LINK E
FUSIBLE LINK F
FUSIBLE LINK G
FUSIBLE LINK H
FUSIBLE LINK HOLDER
FUSIBLE LINK HOLDER (RIGHT REAR OF ENGINE COMPT)
FUSIBLE LINK J
FUSIBLE LINK J FUSIBLE LINK H
FUSIBLE LINK K
FUSIBLE LINK K FUSE 36 FUSIBLE LINK N
FUSIBLE LINK L
FUSIBLE LINK M
FUSIBLE LINK M FUSE 34 FUSE 32 FUSE 33
FUSIBLE LINK N
FUSIBLE LINK Q
GRN WIRE
GRY WIRE
HORNS SYSTEM
HORNS, STARTING/ CHARGING SYSTEMS
HORNS, STARTING/ CHARGING SYSTEMS ENGINE CONTROLS SYSTEM
IND
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
LOCK IND
LT BLU WIRE
LT GRN WIRE
LUGGAGE ROOM POWER SOCKET
NAVIGATION, SOUND SYSTEMS
NCA WIRE
ON IND.
PASSIVE RESTRAINTS SYSTEM
PNK WIRE
PPL
PUSH BUTTON IGNITION SWITCH
PUSH SW
PUSH SWITCH
PUSH-BUTTON IGNITION SWITCH (PUSH SWITCH)
RED WIRE
RIGHT END OF DASH)
SEATS SYSTEM
SOUND SYSTEMS
STARTING/ CHARGING SYSTEM
TAN WIRE
TO (IPDM E/R) ECM RELAY (DIAGRAM 3 OF 3)
TO (IPDM E/R) FUSE 58 (DIAGRAM 3 OF 3)
TO (IPDM E/R) STARTER RELAY (DIAGRAM 3 OF 3)
TO ACCESSORY RELAY (DIAGRAM 2 OF 3)
TO FUSE BLOCK (J/B) IGINITION RELAY (DIAGRAM 2 OF 3)
TO FUSIBLE LINK HOLDER FUSIBLE LINK S (DIAGRAM 2 OF 3)
TRANSMISSIONS SYSTEM
TRANSMISSIONS, CRUISE CONTROL SYSTEMS
TRUNK, ENGINE TAILGATE, CONTROLS FUEL DOORS SYSTEM HORNS SYSTEM SYSTEM
TRUNK, TAILGATE, FUEL DOORS SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 3) -> ELECTRONIC PASSIVE POWER RESTRAINTS STEERING SYSTEM SYSTEM
